Six Channel Hybrid Handheld Particle Counter - China

The HPC600 handheld laser particle counter is the latest innovation in the demanding application of particle distribution measurements.

It is useful in measuring particle distributions in ultra-clean environments by its single particle counting ability as well as in indoor air quality applications.

The instrument consists of a handheld monitor with a main base unit that allows users to conduct sampling with the portable handheld monitor while easily expanding to multiple functionalities provided by the base unit.

These extended functions include real-time data remote sampling, printing, data downloading, software upgrades, battery charging, etc.

In addition to USB interfaces, the RJ45 interface allows users to conduct remote sampling away from the sampling location via Ethernet/Internet.

The HAL-HPC600 is the world’s first of its kind hybrid handheld optical particle counter.

The instrument is truly a breakthrough for a new generation of particle counters that combine the traditional handheld instruments with functionalities of portable instruments.

It is in compliance with the international standards (JIS B 9925: 1997 and ISO14644-1) and CE certification.

It supports both metric and English systems.

All of its key components are made in the USA, Germany or Japan.

It features high sensitivity, multiple functional capabilities, ease of use and reliability for extremely sensitive environmental measurements and advanced applications.

Applications

Clean environment monitoring

Indoor air quality

Test/Check filter seal and efficiency Trace contamination source

Analysis of particle size distribution Specifications

Light Source Laser diode (>100, 000 hours MTBF)

Sensitivity 0.3μm Size Range 0.3 ~ 25μm Channels User configurable on any channel with 0.1μm resolution (six default channel settings: 0.3, 0.5, 0.7, 1.0, 2.0, 5.0μm)

Counting Efficiency 50±20% @ 0.3μm 100±10% @ 0.5μm

Coincidence Loss <5% @ 70, 000 particles/liter Zero Count <1 count per 5 minutes

Flow Rate 2.83 L /min (0.1cfm)

Sampling Time User defined: (up to 59m59s) and auto repeat (up to 99 times)

Count Limit Warning FED STD 209E (Class 1 ~ 300, 000) or ISO 14644-1 (Class 2 ~ 9)

Measurement Single/repeat/Average Error Indication Count limit, loss of laser power, out of flow calibration (>±5%), insufficient battery

Interface USB, Internal Memory 6000 measurement data (1000 sets)

Power Removable, rechargeable Lithium battery (7.4V/2800mAh) or AC Adapter (input: AC100~240V, output: DC9V/1.5A)

Max.

Operating Time Continuous operation > 5 hours with Lithium battery

Dimensions Handheld: 185 (H) × 93 (W) ×46 (D) mm

Base unit: 152 (Dia.

)× 97(H) mm Weight < 800 grams (including battery)

Environmental Conditions Operating: 5 ~ 45°C, < 90%RH

Storage: -20 ~ 50°C, < 90%RH

Accessories Main base unit, AC adaptor, iso-kinetic probe, USB data cable, remote sampling and data download software (CD), zero-count/purge filter, traceable calibration certificate
