Pore Size Analyzer - China

Filter can test the thickness of (0.1-3) mm.

More than 3mm can be ordered special material fixture.

The test tank and platform dimensions of the filter element can be designed and manufactured according to customer requirements.

Test items:

Integrity (whether the damage of the filter, filter joint, end cap adhesive with or without defects);

The maximum bubble diameter of the first bubble point pressure filter;

The average pore size of the bubble point pressure filter;

Filtering accuracy (βx ≥ 20 corresponds to the reference value).

Test objects:

Oil filter material and air filter;

Oil filter and air filter;

All filter components of the chip filter and filter.

Application Product development and quality control department monitoring center

Quality inspection and supervision institutions

Filter users and filter manufacturers Features

Filter element and filter material is easy to install; The filter element and the filter material are easy to convert to the test state (by adjusting the three-way wrench adjustment); The machine itself comes with an air pump; Temperature compensation.

(Experimental results are not affected by temperature changes); Measurement data time monitoring (LCD display), the test results are intuitive and easy to understand; Come with a printer; Test results can be long-term preservation, easy to query (up to 200); The conversion coefficient between the filter precision and the average pore diameter of the six kinds of filter materials is set.

With exhaust fan, protective cover; Filter automatically tightening, lifting device; A tank can be automatically added liquid, drainage;

Aluminum alloy frame, stainless steel panel, stainless steel test tank.

Standards

ISO 2942: 2004 Hydraulic fluid power -Filter elements -Verification of fabrication integrity and determination of the first bubble point

GB/T 14041.1-1993 Hydraulic fluid power-Filter elements-Verification of fabrication integrity

ISO 4003: 1990 Permeable sintered metal materials; determination of bubble test pore size

GB/T 5249-1985 Permeable sintered metal materials-Determination of bubble test pore size

QC/T 794-2007 Internal-combustion engine industry filter paper Technical Parameters

Items Parameters

Test the maximum pressure 14.99kPa

Aperture test range (5-120)μm

Filter paper thickness range (0.1-3)mm(more than sub-range to be customized special fixture)

Clamp outer diameter φ(88±1)mm

Clamp inner diameter φ(72±0.2)mm

The height of the sample on the liquid (12±3)mm

Test media Recommend with isopropyl alcohol, industrial ethanol

Voltage 380V

Power 40W

Dimensions 1750MM*850mm*1950mm(L*W*H )
