Outdoor Loose Sleeve Layer Stranded Reinforced Armored Optical Cable - China

Outdoor Loose Sleeve Layer Stranded Reinforced Armored Optical Cable

Brand Name: KOLORAPUS

Sample: Available

unit price<=$15, free sample and need to pay the freight.

unit price >$15, need to pay the double sample fee and freight.

MOQ：>=$7000 Payment Method: T/T

Origin: China

Product description:

1 - Full cross-sectional water-blocking structure with special oil paste filling in the loose tube to ensure good water and moisture barrier performance.

2 - Third party inspection report available.

Specification: Standard YD/T901, ISO/IEC11801, ANSI/TIA-568-C.

3

Optical fibre specifications A1b (OM1)

Attenuation @20℃ (dB/Km) @1310≤0.36, @1550≤0.22/@850≤3.0, @1300≤1.0

Number of fiber cores 4/6/8/12/24cores

Reinforcement Phosphorized round steel wire

Inner Sheath material Aluminium-polyethylene bonded sheath

Inner Sheath MDPE, black

Outer sheath material steel - polyethylene bonded sheath

Outer sheath MDPE, black

Permissible tensile force 1000N long term, 3000N short term

Permissible flattening force 1000N/100mm long term, 3000N/100mm short term

Minimum bending radius 25D dynamic, 12.5D static

Laying method direct burial

Temperature range for storage and transportation : -40℃～+60℃, for installation and laying : >-15℃ Order information:

Product name 4-coreModel id 6-coreModel id 8-coreModel id 12-coreModel id 24-coreModel id Packaging Method

Outdoor Multimode Layer Stranded Armored Optical Cable GYTA-4A1b GYTA-6A1b GYTA-8A1b GYTA-12A1b GYTA-24A1b Wooden shaft
