Gas Cylindner Online Test System - China

Application:

Applid to online hydraulic test (water jacket), cylinder valve gas leakage test and body leaking test of varioud carbon fiber cylinders, with rotary/drying device and cylinder valve disassembly and assembly device.

Technical Details: l Hydraulic test (water jacket method) Test pressure: 0～1000 bar (other pressure available) Test medium: water Medium temperature: ambient temperature Test port: 4 ports (more upon request) Pressure rising speed: ≤0.5MPa/S (others upon request) Pressure measure accuracy: 0 - 5%F.S. (higher precision upon request) Pressure measure accuracy: ±1%F.

S Defromation measure method: weighting, flow gauge or measuring cylinder Defromation measure accuracy: ±1%F.

S Timing range: 0～999S Control method: manual or auto Drive air: 0.5MPa≤P≤0.8MPa Power supply: AC 380V 50Hz

Company Contact:

• Posted By: Shenzhen IVS Flow Control Co., Ltd

• Phone: +86 0755-86069900

• Address: Bldg A, Yisong Industrial Park, No. 9, Jie Jiabao Rd, Shuitian, Shiyan, Shenzhen, China 518108 , Shenzhen , Guangdong , China

• Email:

• Website: https://www.ivsna.com

• Business Description: IVS Tester Corporation, founded in 1999, has been focusing on designing the manufacturing test equipments.

  Thanks to SC Hydraulic Engineering Co.

  and High Pressure Equipemnt Co, we had succesfully developped the Hydrostatic & Burst tester, Impulse tester, Leak detection tester, Volumetric Expansion Tester, etc.

  Our prefessional R & D team had made the ultimate tests on ultra pressure and finest precision possible for our heavy national industies including:

  Oil & Gas Industry:

  Hydraulic and Gas Leak test on Well control devices, Wellhead safety valve control panel;

  Automotive Industry:

  Various test stands on Brake hose, Fuel hose, Engine body, Muffler, Safety valves, high pressure pipes;

  Military Industry:

  Missile head cooling system, test stands on Valves and Instruments;

  Aerospace Industry:

  Various test stands on Aerospace hose, valves, and executor;

  Fire protection, Hose and Cylinder Industry:

  Hose tester, Cylinder tester, Impulse tester, Cyclic tester and etc.
