Fabric Pneumatic Stiffness Tester - China

With the infrared beam composition "stealth" detection slope, replacing the traditional tangible slope, to achieve non-contact detection, to overcome the twist due to the specimen is tilted up and affect the measurement accuracy of the problem.

While making the measurement tilt adjustable.

The automatic detection system overcomes the shortcomings of the visualization and enhances the anti-jamming.

Sample pressure plate automatic landing device to ensure that the pressure plate and sample positioning accuracy and consistency, improve work efficiency.

Technical Parameters:

1 - Instrument measurement angle: 41 ° 30 ', 43 °, 45 ° adjustable

2 - Extension length range: 0.5cm-20cm (special requirements can be made in the order)

3 - Numerical display resolution: 0.01cm

4 - Measurement accuracy: ± 1%

5 - Specimen specifications: 2.5cm × 20cm

6 - Work platform specifications: 5cm × 20cm

7 - Sample pressure plate specifications: 2.5cm × 20cm

8 - Sample pressure plate speed: 0.3 ~ 0.5 cm / s (special requirements can be made at the time of order)

9 - Rated power: 45W

10 - Power: single-phase 220V 50Hz

11 - Host volume: 425mm × 250mm × 380mm

12 - Host Weight: 16.5Kg Optional configuration:

1 - Brand laser printer
