Factory Directly Sell 3d Casting Welding Table For Bus Frame - China

1 - Come with five working surfaces, other fixtures and jigs can be

installed on it, and also it is expandable in all five directions

over the full length, width and weight.

2 - Two kinds of material: Steel Welding Table ( Q345) or Casting Welding Tables( HT300)

3 - System bores diameter: D28 or D16

4 - With 100 x 100mm grid pattern of bores for D28 series, and 50 x 50mm for D26 series.

5 - 3 kinds of Legs for customer’s choice: steel frame, hydraulic lift box or heavy duty wheels

6 - Other fixtures and jigs are divided into: Supporting Tools, Locating Tools, Connecting Tools, Clamping and Fixing tools, Locking Tools, and Auxiliary Tools

7 - Economical welding table:

a.

Save much cost instead of reserving a lot of complicated and expensive traditional fixtures

b.

Applies to various working conditions without the need of any modification

c.

Safe and convenient to operate

8 - Flexible design:

a.

can bear extremely heavy loads

b.

any work piece can be fixed and clamped on the table with other features and jigs,

c.

3D welding tables can be linked together against any of its five surfaces.

9 - Precise design:

a.

almost all work piece can be fixed precisely at certain points or surfaces with other fixtures and jigs in the process of assembling or welding.

b.

even imprecise work piece also can be adjusted during preliminary work process.

Product Parameters:

3D Steel Welding Table ( D28) :

Sizes L* W* H( mm) Model No.

Weight ( kg)

1000 x 1000 x 200 WT281010H 500

1200 x 1200 x 200 WT281212H 600

1500 x 1500 x 200 WT281515H 700

2000 x 1000 x 200 WT282010H 650

2400 x 1200 x 200 WT282412H 1000

3000 x 1500 x 200 WT283015H 1700

4000 x 2000 x 200 WT284020H 2600

3D Casting Welding Table ( D28) :

2000 x 1000 x 200 WT282010Z 800

2400 x 1200 x 200 WT282412Z 1200

3000 x 1500 x 200 WT283015Z 1900

4000 x 2000 x 200 WT284020Z 3200

3D Steel Welding Table ( D16) :

1000 x 1000 x 150 WT161010G 500

1200 x 1200 x 150 WT161212G 600

1500 x 1500 x 150 WT161515G 700

2000 x 1000 x 150 WT162010G 650

2D Steel Welding Table ( D28) :

1000 x 1000 x 100 WT281010E 290

1200 x 1200 x 100 WT281212E 390

1500 x 1500 x 100 WT281515E 550

2000 x 1000 x 100 WT282010E 560

2400 x 1200 x 100 WT282412E 670

3000 x 1500 x 100 WT283015E 870

Company Contact:

• Posted By: Changzhou Santuo Welding Equipment Co., Ltd

• Phone: 86051983992955

• Address: n District, Qianhuang Town, Wujin District, Changzhou , China

• Email:

• Website: http://www.czsantuo.com

• Business Description: Changzhou Santuo Welding Equipment Co., Ltd is specialized in the R & D,

  design production, sale and maintenance of 3D modular clamping system.

  The introduction of German technology brought together the industry

  elite, continuous innovation and refine on.
