Wire Wrapped Screen - China

WIRE WRAPPED SCREEN

Wire - Wrapped Screens

Unsurpassed in design, construction and performance, well Screens All-Welded wire-wrapped screen provides field-proven sand control.

The wire-wrapped screen features a keystone-shaped, wedge, vee shaped wrap wire on round rib wires for improved plugging resistance.

Advantages over conventional screens are significant.

· Extra strength

The XINLU WIRE MESH PRODUCTS CO., Ltd wire wrapped screen combines high strength and superior corrosion resistance for unsurpassed durability during installation or retrieval.

The stainless steel wrap wire—firmly welded to every rib wire—is designed not to shift or unwind in the unlikely event should it be damaged downhole.

· Large inlet area

The XINLU WIRE MESH PRODUCTS CO., Ltd screen has a much larger inlet area than conventional wire-wrapped screens.

No solder strips, weld beads or lugs are present to block flow.

Plus, a larger inlet area results in lower entrance velocity for produced fluids, reducing the potential for screen erosion.

· Filtration assurance

With precise gauge control for reliability, gauge spacing of the screen is permanent.

Weld strength and wire orientation are controlled to ensure the gauge required is the gauge delivered down hole.

· Filter Construction

Round wires form the ribs, while the diameter and number are specified by the strength required and size of screen.

Wedge – Vee - Keystone-shaped wire is used for the wrap wires, which are helically wrapped around the preset vertical rib wires.

Each point of contact is welded using a proprietary XINLU procedure.

Wrapping is accurately controlled—resulting in a uniform, precise gauge.

The keystone shape of the wrap wire forms “V” shaped openings between wraps.

This shape opening provides self-cleaning action and greatly reduces flow friction.

Smaller particles can easily pass through the continuous slot while larger ones are held out without inhibiting the total inlet area.

Skype: terastar.

lee

Wechat/QQ: 2315211228

Whatsapp: +86 13315867171

Company Contact:

• Posted By: Feiya International Group Ltd Anping Branch Factory--Xinlu Wire Mesh Products Co.,Ltd

• Phone: +86 13315867171

• Address: Wire Mesh Industrial Zone, Anping County, Hengshui , Hebei , China

• Email:

• Business Description: Feiya International Group Ltd Anping Branch Factory--Xinlu Wire Mesh Products Co., Ltd.

  Our factory produce and sell as following: V shaped wire welded stainless steel water well screens, low carbon steel wedge wire well screens, Johnson Specialty screens, v wire water well screens, wire wrapped screen pipe, welded wedge wire screens, reverse rolled screen tube, spiral screen tube, screen cylinders, rod based continous slot v wire water well screens, water filter, filter nozzle, stariner nozzle, screen nozzle, sieve bend, arc screen plate, wire wrapped panel, flat wedge wire panel with frame, screen beskets, filters basket, vibrating sieve screen, wire wrapped liner, chain link fence, fence netting, welded wire mesh, crimped wire mesh and wire mesh, etc.

  The products are used in drilling well / pump, the trades, such as ore choosing, petroleum, chemical industry, electron, transportation, plastics, food, architecture, traffic , etc.

  Our products can be seen everywhere in China, as well as African countries, Middle East and the regions of Southeast Asia.
