Unique Designed Bagasse Dryer For Green Economy - China

Bagasse refers to sugarcane granular waste left after crushing and pressing.

There are 2 to 3 tons of bagasse to produce one ton of sucrose.

Bagasse is rich in cellulose, and less lignin, so bagasse is great fiber material.

Fresh bagasse is irregular loose particles, low density, poor combustion characteristics, inconvenient to transport, storage and use.

After drying the density, durability, combustion characteristics of bagasse will be improved, and easier to transport and storage.

The dry cane sugar residues is good biomass energy.

Bagasse drying can use boiler flue gas drying.

Sugar plant boiler flue gas temperature is usually between 160 ~ 180 ℃, still has a great value of thermal energy.

The hot air will be extracted from the boiler flue and sent into the dryer by induced draft fan.

With the function of gravity and rotary drums, bagasse will be suspended in the drying unit and fully mixed with hot air, then a lot of water will be evalopated.

The important conversion from high humidity to low humidity, from high viscosity to non-stick will be completed; Under the effect of material lifting system, material will be constantly thrown and raised in the drying unit to form a uniform material curtain and fillup the drying space, thus more adequately contact with hot air.

It maximizes the utilization of heat, enhances evaporation intensity.

The water vapor will discharge from the end of the first level drum.

The secondary cylinder is counter flow plus vortex drying.

Material movement trend reverse fresh hot air flow.

The turbulence will greatly improve, while heat transfer will increase, the drying efficiency also improve, so as to accelerate water evaporation.

Finally, under the action of special pusher plate, the material automatically enters the third-stage dryer.

The third level drier is intersect flow plus reciprocating drying.

Under the action of hot air and special plate, wet materials move slowly and dry time and again, dry materials move fast and firstly, while meeting drying requirements, automatically discharged.

Fresh sugar cane bagasse moisture between 48% to 50%, after a special dryer for sugarcane, moisture content can be below 12%.
