Ip66 Watertight 63a 24 Modules Socket Outlet Combination Units With Cee Ip6 - China

A24MD01-4

Dimension: 360*340*310MM

Input: 1 CEE plug 63A 3P+N+E 415V~IP67 HTN0351

5G10.0 sq mm cable 2.2M

Output: 2 Socket 32A HTN4251

2 Socket 16A HTN4151

2 Socket 16A HTN4131

2 Socket 32A HTN4231

Protection fuse: 1 RCD 63A 4P 0.03A 400V~

2 MCB 32A 3P 400V~

2 MCB 16A 3P 400V~

2 MCB 32A 1P 230V~

2 MCB 16A 1P 230V~

● The box could include 24pcs of 1P MCB( the width of 1P

MCB is 18mm)

● The Socket(SCHUKO) could be changed to

British, French, Danish, Swiss and Australian Sockets

★ Trade Mark: HTCN®

★ Pre-wired for Installation

★ Fusing under the cover

★ Can be locked by a padlock

★ Protection degree: IP66 (waterproof)(watertight)

★ Material: Flame Retardant Thermoplastic RoHS Reach

★ Operation Temperature: -25℃~+40℃

★ Certificates: S, CB, CE, TUV, ISO9001: 2008, RoHS, REACH

★ Standards: IEC/EN60439-1, IEC/EN60439-4

★ Package: Polybag + 1pcs/Inner Box + 1pcs/Export carton

> Distribution boxes for flexible current supply, portable

and handy, ;

> High resistance to weathering and chemicals;

> All combinations are tested for electrical safety and

quality;

> IP44, IP55, IP66 protection degree against dust and liquid

bodies;

> IK8 mechanical protection degree;

> High quality thermoplastic material;

> Available component preset as requested;

> Widely used in the following sites, such as: Repair,

extension and demolition, work on existing buildings,

Construction sites, Exhibition center, Factories, etc.
