Ywx Q 010 Salt Spray Test Machine - China

The Salt Spray Test Machine/Chamber is applicable to the salt spray

corrosive test for the protection layer of components, parts, electronic

and electrical parts and metal materials and industrial products.

Model Work Room Size (mm) Exterior Size (mm) Voltage Power (KW)

YWX/Q-150 450X600X400 800x1070x1050 AC220 2.5

YWX/Q-250 600x900x500 870x1400x1150 AC220 3.5

YWX/Q-750 750x1100x500 1030x1680x1260 AC220 4.5

YWX/Q-010 850x1300x600 1160x2000x1390 AC380 6.5

YWX/Q-016 850x1600x600 1280x2320x1500 AC380 9.5

YWX/Q-020 900x2000x600 1220x2530x1410 AC380 11

Specifications:

• The Salt Spray Test Machine is made of transparent materials so that the operator can see the tested sample in it and the spraying situation of the tested sample.

• A waterproof structure is adopted between the chamber cover and chamber body, thus there is no salt spray overflow.

• Adopts the tower spraying system and equipped with the salt solution filter system and non-crystal nozzle so as to realize even salt spray distribution and freely adjustable settlement.

• Control System High precision P.I.D.

temperature control meter with its error ±0.1℃.

• It meets the following standards: IEC60068-2-11(GB/T2423.17 ), GB/T10125, ISO9227, ASTM-B117, GB/T2423-18, IEC 60068-2-52, ASTM-B368, MIL-STD-202, EIA-364-26, ASTM-B117, GJB150, DIN50021-75, ISO3768, 3769, 3770; CNS 3627, 3885, 4159, 7669 etc.
