Tm 8818 Ultrasonic Thickness Meter - China

Applications

Used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, etc.

in industries of petroleum, shipbuilding, power station, and machine manufacturing.

Details

Case Material   Aluminum Alloy

 Display  4 Digit LCD

 Operating Principle  Ultrasonic

 Measuring Range ( metric / Imperial)  0.9~400 mm ( 45 # steel )

 Battery Indication  Low Battery Indication

 Sound Velocity  1000~9000 m/ s

 Lower Limit Steel Pipes  Φ20 x 3.0 mmÂ

 Calibration Block  Included

 Resolution  0.01 mm /  0.1 mm

 Accuracy  ± ( 0.5% n + 0.1)

 Automatic memory material code and the value of sound velocity

 Power off  Auto Power off & Manual Power Off

 Operating Conditions  Temperature: 0~40 °C, Humidity: < 85 % RH

 Power Supply  2 x 1.5 V AA ( UM- 3) Battery

 Dimensions  130 x 76 x 31 mm

 Weight  340 g ( Not Including Batteries)

Standard Accessories:

 1 - Main Unit

2 - 5MФ8 Standard Sensor Â

3 - Coupling Agent Â

4 - Carrying Case

5 - Operating Manual

Optional Accessories:

 1 -  6M Φ6 mm thin Material Probe : Measuring range ( steel) : 1.0~50.0 mm Operating temperature: - 10~60°C

 2 -  5M Φ12 mm High Temperature Probe: Measuring range ( steel) : 1.0~225.0 mm ( normal temperature) Measuring range ( steel) : 4.0~100.0 mm ( high temperature) Operating temperature: - 10~300°C

 3 -  Curved Surface Probe

 4 - USB, RS- 232C data cable with software
