Submersible Water Level Meter - China

Description of submersible water level meter:

YD322- II liquid level transmitter is compose of full sealed isolation membrane oil- filled level sensor and special instrument circuit.

With the advantages of high measuring precision, good stability, long service life, convenient installation, etc.

With unique technology of sealing structure form, and good anti- leakage performance, immersed in a liquid reliable operation for a long time.

Specifications of submersible water level meter :

1) .

Measurement object: liquid level of water, oil, paste

2) .

Measuring range: 0 - 200m

3) .

Output signal: 4 ~ 20mA or 0 ~ 10mA

4) .

Power supply voltage: 24VDC

5) .

Temperature: - 20 to 80℃

6) .

Index Table: user select

7) .

Material: die- casting aluminum alloy shell, epoxy coating surface

8) .

Diaphragm: 316 stainless steel

9) .

Probe: 1Cr18Ni9Ti

Pressure Range

0- 1 0- 2 0- 5 0- 10 0- 20 0- 30 0- 50 0- 100 0- 150 0- 200m

Accuracy

±0.1% ±0.2% ±0.3% ±0.5%

Power Supply

24VDC ( 12- 30VDC)

Signal Output

Two Wire: 4- 20mA 0- 10mA

Three Wire: 1- 5VDC 0- 5VDC

Operating Temperature Range

- 20 to 80℃

Connection Size

Inputting Type: Φ22 or Φ27

Pipe connection: M20* 1.5

Flange connection: DN50 or DN30 or customized

Medium

Liquid compatible with 316LSS
