Rosemount 2090p - China
price: contact company for price
Product Description
With its compact size and rugged construction, the Rosemount 2090P Pulp and Paper Pressure Transmitter is ideal for the pulp and paper industries.
This lightweight transmitter is engineered with a 1 in.
flush mount compatible with PMC process connection or 1 1/2 in.
threaded mounting connection.
This transmitter can be calibrated to ranges as low as 0 to 1.5 psi (0.1 bar) and as high as 0 to 300 psi (20.7 bar) for reliable measurement capabilities.
Specifications
Measurement Type
Gage, absolute
Accuracy
Up to ±0.10% of span
Stability
±0.10% of Upper Range Limit (URL) for 12 months
Warranty
Up to 5-year limited warranty
Rangedown
Up to 20: 1
Communication Protocol
4-20 mA HART®
Measurement Range
Up to 300 psig (20, 7 bar) Gage, Up to 300 psia (20, 7 bar) Absolute
Process Wetted Material
316L SST
Diagnostics
Basic Diagnostics
Certifications/Approva ls
Hazardous location, see full specs for complete list of certifications Features
•
1 in.
flush mount compatible with PMC process connection or 1 1/2 in.
threaded mounting connection available
•
Calibrates as low as 0 to 1.5 psi (0.1 bar) and as high as 0 to 300 psi (20.7 bar) for application flexibility
•
Lightweight, compact design for easy installation
•
Fully configurable LCD displays process variable, percent of range and diagnostic message
•
Communicates via 4-20 mA HART® protocol for streamlined host integration
Company Contact:
- Posted By: Xi'an Yunyi Instrument Co., Ltd
- Phone: 00862988812007
- Address: Room 1203B, Inland Port Mansion, No.9 Gangwu Road, Xi an International Trade & Logistics Park, X, Xi'an , Shaanxi , China
- Email:
Published date: March 24, 2017
- Business Description: Professional manufacturer pressure transmitter, pressure gauges, pressure calibrator and deadweight tester.
And we also develop valves, flow meter, temperature transmitter, level transmitter, densitometer etc.
They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
