Pancake Slip Ring For Medical Equipment - China

When you have a height restriction, a "pancake" slip rings - also called a "flat" or "platter" ring - could be the best solution.

These slip ring units are based on a disc shaped rotor, which is embedded with concentric grooves to carry the signal and power, with a brush block assembly mounted over the top to act as the stator.

We can customize this type of slip ring from 4 to 50 channels, and any center bore size.

Contacts use precious metals and operating speed depends on the number of channels and overall size of slip ring.

(More product information welcome to visit slipring.

net.

)

A.

)Features:

● Ultra-thin design, the thickness reaches 15 mm min;

● Center bore size can be customized;

● Multi circuits/channels design can deliver both power & signal at the same time;

● No need to maintain.

B.

)Specification Channels 1~50 Ways

Voltage 240V AC/DC

Current Rating 2A/Ring

Speed 100PRM

Insulation Resistance 1000MΩ@500VDC

Dielectric Strength AC600V@60Hz, 60S

Electrical Nosie 60 milliohms MAX @ 5~10 rpm, 50milliamps, 6V DC

Lead Size/Type AWG28 Sliver plated coppe, Type ET Teflon

Lead Lengths 250mm

Operate Temp -20℃～+80℃

Storage Temp -30℃～+90℃ Our products are widely used in: Security, Factory Automation, Electric Instrumentation, Medical, Aerospace, Marine, Civil and Military Fields.

Such as: Crane, Giant Wheel, Cotton Picker, Medical Equipment, Detector, Rotary Tables, Robots, Strander, Webcam, Automatic Revolving Door, Exhibit / Display Equipment, Food Manufacturing Machine, Packaging Machine, Amusement Equipment, Irrigation Machine, Heated Rollers etc.

More product information welcome to visit our website.

Company Contact:

• Posted By: Victory-way Electronic(Shenzhen) Co., Ltd

• Phone: +86-755-2780 6979

• Address: BLD.D, Hejing Industrial Park, Heping Fuyong, Baoan District Shenzhen,China, Shenzhen , Guangdong , China

• Email:

• Business Description: Victory-way Electronic(Shenzhen) Co., Ltd. is a high-technology company which focuses on R&D and production of industrial electrical slip ring, created by senior engineers with many years of conductive slip ring application and development experience.

  So we can learn the demands of customers better and provide the best solution in the shortest time to help customers shorten development time.

  We design, develop and produce fiber composite (FORJ), electrical liquid mixture, high-frequency combinations, explosion-proof slip rings, waveguide combination of slip rings, etc.

  and we can provide the electrical contact devices in varieties of working conditions, from the underwater environment to the high altitudes, from the alpine zone to the high temperature environment, and even for the explosive condition.

  At present, our products are applied in the fields of security, industrial automation, military, environmental protection and so on.

  Excellent performance and reliable quality make our conductive slip ring exported to developed industrial countries, such as Japan, USA, Europe etc.

  Our products are very popular with customers and we are honored to be privileged the only supplier of slip ring for some customers of the high reliability requirement.

  We will continue to work hard to provide high quality conductive slip ring and the best solutions to customers.
