Microcyber Intelligent Pressure Transmitter - China

Specifications1 - support FF, PA, HART protocols, 2 - with

advanced, mature, reliable Piezoresistive Silicon Sensors.

Intelligent Pressure Transducer with LCD Display

Feature

1 - Support lots of protocols

2 - High accuracy, better reliability and intrinsically safety

3 - Accuracy: ±0.075% (20°C, range rate10: 1)

4 - Support EDD, GSD and DTM

5 - EMC: According to IEM61326

6 - Protection degree: IP67EDD, GSD and DTM

General Introduction

NCS-PT105ⅡS series Smart Pressure Transmitter with

advanced, mature, reliable Piezoresistive Silicon Sensors

has been designed meticulously by com bining advanced

microprocessor technology and digital capacitance

measurement techniques.

The powerful functions and high-speed computing capability

of the microprocessor make it have excellent qualifications

such as intelligent, high-precision, high reliability,

stable zero and so on.

Its LCD can display many physical

parameters such as pressure, temperature, current.

It can be

realized zero adjustment, range settings and other features

by key-press operation, and easy to on-site tests.

NCS-PT105ⅡS series Smart Pressure Transmitter supports

HART, FF, Profibus PA, Profibus DP protocol and can measure

pressure, differential pressure, liquid level, flow, and

other industrial parameters.

It can be widely used in the

petroleum, chemicals, electricity, and metallurgical

industries, etc.

Model Selection of NCS-PT105IIS Pressure Transmitter

(Piezoresistance Silicon Sensor)

Model Pressure type

NCS-PT105ⅡS SG Gauge pressure transmitter

NCS-PT105ⅡS SA Absolute pressure transmitter
