Interior Materials Flammability Test Machine - China

Products

Thistester is under the terms of the ISO3795 standards specified in the relevant design and manufacturing.

Apply to identify vehicles (cars, multipurpose passenger car, truck and bus) interior material horizontal burning test.

Car inner decorations combustion tester is composed of test part and control part adopts the integrated design, convenient installation and debugging.

A high degree of automation control system, with functions of automatic ignition.

Temperature and time digital display, easy observation records, the use of stable and reliable.

ModelFTech-ISO3795A


Standards FMVSS 302 Federal Motor Vehicle Safety Standard 302 ISO 3795 GB / T8410-2006

Features:

Advanced industrial appearance and control design

1, Stainless steel structure housing; bottom ventilation hole spacing: horizontal 63.5mm, longitudinal 127mm.

2, the number of ventilation holes: 10, diameter 19mm.

3, an inner diameter of the burner Φ9.5mm.

Blowtorch top center at the free end of the specimen from 19mm

4, glass doors for easy observation test;

5, equipped with: stainless steel sample holder and sample templates;

6, the combustion chamber built steel ruler; precision: 1mm; combustion length can be easily read; do not remove the sample measurement burn length;

7, using a Bunsen burner the United States import Hamburg, flame higher accuracy, adjustment range 20mm ~ 100mm.

8, the flame measuring device; flame height 38mm

9, automatic ignition, automatic timing;
