Iec60695 11 5 Needle Flame Tester - China

According to IEC60695- 2- 2 and IEC60695- 11- 5, ZY- 3 Needle Flame

Tester is applied in the production and quality control department of

lighting instrument, hypopiesis electrical apparatus, domestic

appliance, machine electric appliance, electrical machine, power tool,

electronic instrument, electrician instrument and technical equipment.

Also, it is fit for the industry of insulation material, engineering

plastics and solid combustible material.

Technical Parameters

Burner Angel: 0°, 20°, 45°

Flame Height: 12±1mm

Needle burner: Height above 35mm, Stainless steel needle Φ 0.9mm- Φ 0.5mm

Standard Copper Block: 0.58±0.01g

Check time: 23.5±1S

Temperature Test: MAX1050°C ±0.1%

Thermocouple: RS ( British) , Type KΦ 0.5, accuracy ±0.05%

Gas variety: Butane or purity above 95% , Propane
