Gradient Heat Seal Tester Hot Machine - China

Gradient Heat Seal Tester is for the determination of the

heatsealability of a surface, or sealant layer of films, laminates,

composites and polymers etc.

How well the material heatseals is

expressed quantitatively as seal strength as a function of the sealing

conditions of temperature, time and pressure.

Gradient Heat Seal Tester Standards

ASTM F2029, QB/ T 2358, YBB 00122003

1 - Five groups sealing temperature can be measured with one test

2 - Proximity and pressure sensor for precise dwell time and sealing pressure control

3 - P.

I.

D.

for precise sealing temperature control

4 - Uniform heating by aluminum encapsulated sealing jaws and no inhomogeneous heating

5 - Independent heating of upper and lower sealing jaws

6 - Sealing jaw customization available in term of dimension, shape and surface

Gradient Heat Seal Tester Specification

Sealing temperature Room Temperature ~ 300℃

Deviation ±0.2℃

Dwell time 0.1 s~990H

Sealing pressure 0.15 MPa ~ 0.7 MPa

Sealing Jaws 40mm×10mm×5( Sealing Surface) ( Customization Available)

Double Heating of Upper and Lower Jaws

Gas Pressure 0.5 MPa~0.7 MPa of Air

Dimensions455mm ( L) * 320mm ( W) * 440mm ( H)

Port Size Ф 6 mm PU Hose
