Gd 261d Automatic Pmcc Flash Point Tester - China

Purpose:

The instrument is designed and made as per the National

Standard of People’s Republic of China GB/ T261 “Test

Methods for Flash Point of Petroleum Products ( Closed Cup

Methods) ”.

It is suitable to determine closed cup flash

point of petroleum products, which is described as the

lowest temperature at which the mixture of a petroleum

product sample vapor and air contacts flame and makes a

flash when the sample is heated in a closed cup under the

stipulated condition.

I Main technical characteristics

1 - It adopts colored LCD, man- machine conversation

interface, and blank buttons.

It has prompts menu and guide

to preset temperature, sample serial number, barometric

pressure, test data and other parameters.

2 - It can simulate and show temperature- time curve.

It has

prompts for wrong operation and prompts to modify test data,

test time, and other parameters.

3 - It can save test data of 100 groups.

It is equipped with

RS- 323, and 485 computer ports, so it can save more test

data when it is connected to a computer.

Then you can also

modify some parameters.

4 - It can calibrate the effect of barometric pressure to the

test and calculate the modified value.

5 - Differential detection.

It can modify system deviation

automatically.

6 - It can open lid, apply flame, make detection, and print

test data automatically.

The test arm can be raised up and

lowered down automatically.

7 - It uses an electron igniter for flame ignition.

It has

forcible wind cooling function.

II.

Main technical specification and parameters

1 - Power supply: AC 220V±10% , 50 Hz;

2 - Temperature measurement:

( 1) Measurement range: room temperature~300°C;

( 2) Repeatability: ≤ 2°C;

( 3) Reproducibility: ≤ 4°C;

( 4) Resolution: 0.1 °C;

( 5) Accuracy: 0.5% ;

3 - Basic parameters:

( 1) Temperature rising speed: as per the GB/ T261;

( 2) Ignition mode: by an electron igniter; gas flame for

flame application;

4 - Ambient temperature: 10~40°C;

5 - Relative humidity: ≤ 8°C;

6 - Total power consumption: not more than 300 W
