Fdt 0481 Automatic Viscometer - China

Scope

the Automatic viscometer used by the GB / T265-88, GB / T11137-89, ISO3104, ASTMD445, ASTM D446 requirements, determination of liquid petroleum products (Newton liquid) kinematic viscosity in units of m2/s, usually use mm2/s in practice.

Dynamic viscosity of the liquid at a constant temperature measured kinematic viscosity and density of the product at the same temperature of the liquid.

Automatic viscosity measuring instrument measuring transparent and opaque liquids, including crude oil, light and heavy fuel oil, lubricating oil additives, oil kinematic viscosity.

Features

1, a person is not required to follow the automatic operation of the instrument, the operator in the loft, you can leave the scene, the instrument can automatically complete all tasks.

2, automatic intelligent control system, auto-complete product preheating, automatic detection, automatic storage, automatic cleaning of the whole process.

3, wide measuring range, select the range, this product is imported viscometer, accurate and reliable measurement, measuring range up to (0.5 ~ 5000) mm2 / s, the range can be customized according to user requirements.

4, Flanders automated imaging discriminating proprietary technology, accurate detection of liquid level; the whole experiment is clear, intuitive display, easy operation personnel at any time during the test the instrument, the results were compared.

5, imported Connon more balls capillary, high precision and more accurate results.

6, imported from Germany vitreous temperature sensor, accurate and reliable data

7, using computer automatic viscosity control system, friendly man-machine interface

8, high-precision temperature measurement and control system, the test temperature is lower than room temperature, and loop system can be equipped with a cold water bath.

9, the integration of design, management, maintenance is simple, fast

10, can be upgraded to wireless processing system, the customer can be optional

Technical Parameters

1, the control mode: computer-controlled, automatic detection

2, the detection system: FLD special detection equipment, high temperature resistance, corrosion resistance, high stability

3, chip processing: US chip imports XECOM

4, Power supply: AC 220V ± 10%, 50Hz

5, temperature control point: 40℃, 50℃, 80℃, 100℃, temperature control accuracy: ± 0.1℃

6 Results Print: Auto Print Report

7, time measurement resolution: 0.01s, maximum timing: 999.9s, timer reference frequency accuracy: ≤0.05%.

8, ambient temperature 5 ~ 35 ℃, relative humidity of 35% -95%

9, the instrument rated voltage of 220V ± 10%, frequency 50Hz ± 1Hz
