Computer Control Electronic Universal Testing Machine - China

Introduction:

tensile, compression, bending, torsion, shearing testing and researching with variety of metal, nonmetal material and composite material under room temperature.

testing and providing data according standards of GB, ISO, JIS, ASTM, DIN, BS and other international standard.

sample of thin plate, panel, belt, foil, flat bar, wire, bar, proximate matter, pipe, sheet, square, round, rectangle, and annulus shaped, cast iron, nonmetal alloy of cast iron, pipe section, proportional and nonproportional, fully wall thickness of longitudinal and horizontal peeling strip, rectangle and round section.

tensile, compression and bending test with varety of material by adding gripper.

tensile, compression and bending test with variety of rubber, plastic, film and other nonmetal material

test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam.

test with textile, food, medcine, cosmetic, biological material.

tensile, peeling and welding strength test with electronic component.

test with wooden, paper, film production and other nonmetal material.

strain relaxation and adhesive strength test.

Important specification

WDW-1kN/2kN/5kN/10kN/2 0kN/50kN/100kN

Electronic Universal Testing Machine (Standard type)(CE)

1

Max.

test force

5kN/10kN/20kN

30kN/50kN

100kN

2

grade of machine

Gradeof 0.5/ 1

3

measure range of loading

0.4%~100%FS (grade of 0.5) /1%~100%FS (grade of 1)

4

relative error of indicating value

Between ±0.5%(grade 0.5) /±1.0% (grade 1)

5

resolution of force

1/±300000FS (resolution of fully stroke is not changed)

6

measure range of deformation

0.2%~100%

7

adjusting range of speed for force controlled

0.005%~5%FS/S

8

Control precision of speed for force

When speed is <0.05%FS, between ±1% of setting value

When speed is ≥0.05%FS, between ±0.5% of setting value

9

adjusting range of speed for deformation

0.005~5%FS/s

10

precision of speed for deformation

When speed is <0.05%FS/s, between ±1% of setting value

When speed is ≥0.05%FS/s, between ±0.5% of setting value

11

adjustable range of speed for displacement

0.001~600mm/min (customized high speed of system 0.001~2000mm/min)

12

control precision of speed for displace

Between ±0.2% of setting value

13

constant force, deformation, displacement control range

0.5%~100%FS

14

control precision of constant force, deformation, displacement

When speed is ≥10%FS, between ±0.5% of setting value, When speed is <10%FS, between ±1% of setting value.

15

effective test span

400mm

400mm

500mm

16

moving stroke of transom

1000mm

1000mm

1200mm

17

voltage

~220V±10% 50Hz (reliable landing)

18

Rate of machine

400W

750W

2000W

19

size of loading frame(LWH)

860x460x1750mm

940x520x1850mm

1050x560x2150mm

20

weight

≈300kg

≈500kg

≈800kg
