Brake Oil Fluid Stroke Simulation Tester - China

Scope

Brake fluid stroke simulation analyzer suitable for assessing the performance of the brake fluid and lubricating properties of the material to adapt, in the test requirements prescribed totals 85, 000 times stroke trials to observe the changes related materials.

Features

1, a cast iron brake master pump, bore: 28.58mm ~ 28.65mm, aluminum pistons, Diameter: 28.52mm ~ 28.55mm;

2, three brake wheel cylinder, bore: 28.60mm ~ 28.66mm, aluminum pistons, Diameter: 28.52mm ~ 28.55mm;

3, a special pump to adjust the mounting plate;

4, the main pipe using uncoated steel;

5, a standard drive mechanism, can produce 8 Mpa working pressure;

6, the figures show that the rate of stroke, with adjustment device;

7, no radiation heating system;

8, rubber cup meet the standards;

9, microcomputer temperature controller, digital display, temperature range: 20 ~ 150 ℃ ± 2 ℃, PT100 temperature sensors, high precision;

10, working pressure gauge display, precision regulator valve to adjust the pressure: 7Mpa ± 0.3 Mpa;

11, digital timer, the wind sounded alarm;

12, fully enclosed refrigeration compressor, reducing cycle gas chamber temperature;

13, integrated structure, easy to operate;

Technical Parameters

1, applicable standards: ISO4925

2, pressure range: 7Mpa ± 0.3 Mpa

3, the pressure control: Precision regulator valve

4, the pressure display: Precision pressure gauge

5, the stroke rate: 1000 times / h

6 trips: 85000 times

7, the temperature range: 20 ~ 150 ℃ ± 2 ℃

8, temperature control: Digital PID temperature controller

9, Refrigeration: Refrigeration Compressors

10, time: digital timer

11 Alarm: the wind sounded alarm
