Box Compressive Strength Tester - China

Box Compressive Strength Tester is for the compression strength and

stacking ability of medium and samll size packagings like

corrugated carton.

Box Compressive Strength Tester Technical Feature

LCD display, PVC operation manual, human design

Microcomputer processing system, automatic measurement, test result intelligent judging, self- reture

Microcomputer data collecting and computing, microprinter

Real- time display of compression resistence force, deformation and changing curve

Three test modes of compression resistence, stacking and compression at fixed time and pressure

Synchronous motor

Accurate thread lead screw drive system

Technical Data

Pressure range: 0- 10KN

Force resolution: 0.1N， Display error: ±2%

Display variation: ≤ 2% ， Back to zero error: ±0.2% FS

Deformation measurement accuracy: ±1mm

Compressing speed adjustable range: 5mm/ min～ 90mm/ min

Compressing speed relative error: ±3% ( within 5～ 90mm/ min)

Standard compressing speed: 12mm/ min

Stacking test speed: 5mm/ min

Lower platen stroke: 800mm

Test space: 400mm( L) * 600mm( W) * 600mm( H)

Upper and lower platen parallelism degree: ≤ 1mm

Dimension: 850mm( L) * 600mm( W) * 1100mm( H)

Weight: 200kg

Box Compressive Strength Tester Standard ISO2874 Tappi T804
