Product Profile

The product is a metal cased, anti-vandal, 1200 users standalone controller, with built-in proximity card reader module and keypad.

It is ideal for high traffic and extremely harsh environments, the unit is fully sealed, epoxy filled and has advanced programming options as well as flexible operation models.

The unit accepts up to 1200 users and provides entry via the user of proximity cards and/or PIN codes.

The proudct has strong functions and advantages such as low power consumption, keypad with blue backlighting, independent passwords, standard prox + PIN code keypad wiegand output, the output short circuit protection, Tamp alarm , exit button, the doorbell interface, etc.

, which is widely used at home, office, residential area and other public places.

Features

A) Standard alone controller:

1) 1200 users capacity

2) door release time adjustable from 1 to 25 s

3) open door with 3 models: PIN only, Prox only and Prox+PIN

4) enrol/delete card by keypad, or master card

5) delete card by input card number from keypad directly

6) optical Tamp detection and buzzer alarm function

7) blue backlight LED for keypad

B) Standard alone secure controller:

Controller is with an external wiegand26 reader input interface, So unit can be installed inside with an external proximity card reader or keypad installed outside of the region to make controller system much securer.

C) Keypad + Prox reader

Unit is with standard wiegand output interface, So it works as a standard keypad + Prox.

reader .

Once card is detected, the card number will be sent via wiegand interface, Once any key is pressed, the key value will be sent via wiegand interface

D) Tamp and bell function

Tamp alarm: when unit is installed well, the optical tamp CDS is in high resistance status and the Tamp output (Pink wire) is in high level, when tamp alarm is active, unit will sound alarm beep and Tamp output (pink wire) will go to low level as notification

Bell key: when Bell key is pressed, the bell output wire (pink wire) will output a lower pulse, to active door bell sound

Technical Specification

Wide Range Operating Voltage Range:

7 to 30V DC From a Regulated Power Supply

Maximum Input Current:

Standby: 30mA Not including attached devices

Max: 100mA Not including attached devices

Relay Outputs:

Door Relay Form C, 3A/30VDC

Inputs:

REX for door , N.O., Dry Contact

Wiegand interface for external reader or keypad input

LEDs

Two Tri-colored LEDs

Blue backlight keypad led

Tamper alarm function

optical tamper detection output

Built-In Proximity Reader

Read Range 4-10 cm , Modulation ASK at 125kHz

Compatible Cards All EM Cards (125Khz proximity or Mifare version are also available)

Operating Temperature: -22 F to 150 F (-30 C to 65 C)

Operating Humidity: 0 to 95% (Non-Condensing)

Suitable for outdoor use.

(IP 65)

Dimension : 120mm L x 58mm W x 20mm D

Weight : 500g

Equipment provided

The following is provided as part of every package:

- main Access Control Unit.

- Installation Kit

- Installation and Operating Instructions
