Mining 14 Ton Xiangtan Trolley Locomotive - China

Mining 14-ton Xiangtan trolley locomotive Selecting the appropriate wheelbase for mining Xiangtan electric locomotives is a critical decision, as it directly influences the turning radius and overall stability during operation.

Generally, a longer wheelbase results in a larger turning radius, while a shorter wheelbase allows for a smaller turning radius.

However, the choice of wheelbase depends on specific factors such as industrial and mining conditions and the minimum turning radius of the track.

Consideration of Turning Radius:

The turning radius of a locomotive is a key factor affected by the wheelbase.

A larger wheelbase generally corresponds to a larger turning radius, making it suitable for environments where wider turns are required.

Conversely, a shorter wheelbase allows for a smaller turning radius, making it more appropriate for navigating tight corners and confined spaces.

Stability and Smooth Operation:

In addition to turning radius considerations, the stability of the locomotive during operation is crucial.

Longer wheelbases contribute to smoother rides and enhanced stability.

The choice of wheelbase should align with the need for a steady and secure operation, especially in challenging mining environments.

Adapting to Industrial and Track Conditions:

The decision on wheelbase selection is highly dependent on the specific conditions of industrial and mining operations.

Factors such as the layout of the tracks, the nature of the materials being transported, and the operational requirements all play a role in determining the ideal wheelbase.

Conclusion:

In conclusion, the selection of the wheelbase for mining Xiangtan electric locomotives is a nuanced decision that involves balancing turning radius, stability, and operational requirements.

By carefully evaluating the industrial and mining conditions, operators can make informed decisions to ensure optimal performance and safety in their locomotive operations.

Total weight (t) : 14 ton

Track gauge (mm) : 600.762.900

Traction (KN) : 26.68

Max.

Traction (KN) : 34.3

Speed(km/h) : 12.87

Power (KW) : 52*2

Dimensions

Length(mm) : 4800

Width(mm) : 1060, 1222or 1360

Height(mm) : 1700

Wheelbase (mm) : 1700

Wheel diameter (mm) : 760

Min Curve radius (m) : 12

Controller : Resistencia or IGBT

Braking method : Mechanical
