Cjy7 Ton Mining Trolley Electric Locomotive For Underground Metal Mine Tunnel - China

Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines.

Mainly used in mines where there is no risk of explosion.

Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range.

Therefore, it is suitable for long-term and long-distance use.

There are also many options in terms of speed regulation and braking methods.

Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control.

Braking methods include pure mechanical braking, hydraulic braking and compressed air braking.

In addition, electric braking can also be selected as an auxiliary braking method.

Adhesive / total weight (t) : 7 ton

Track gauge (mm) : 600, 762 or 900

Traction (KN) : 13.05kN/ 15.09kN

Max.

Traction (KN) : 17.2kN

Speed(km/h) : 11km/h

Voltage : 250V or 550V

Power (KW) : 21kw *2 or 24 kw*2

Dimensions Length(mm) : 4550mm

Width(mm) : 1050, 1212 or 1350mm

Height(mm) : 1550mm

Wheelbase (mm) : 1600 mm

Min Curve radius (m) : 7 m

Wheel diameter (mm) : Φ680mm

Controller : Resistance or IGBT or AC controller

Braking method : Mechanical or air Brake
