Cjy5 Ton Trolley Accumulator Locomotive - China

CJY5 Ton Trolley Accumulator Locomotive for Underground Mining Tunnel

We are the real Mining locomotive factory in china, we could provide you with E-online chat to show your our factory! Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines.

Mainly used in mines where there is no risk of explosion.

Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range.

Therefore, it is suitable for long-term and long-distance use.

There are also many options in terms of speed regulation and braking methods.

Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control.

Braking methods include pure mechanical braking, hydraulic braking and compressed air braking.

In addition, electric braking can also be selected as an auxiliary braking method.

C: Locomotive for coal mining

J: Trolley electric locomotives

Y: Single-end driver's cab

G: Steel wheel, resistor for speed control

GB: Steel wheel, chopping wave for speed control Product Description

Adhesive / total weight (t) : 5 ton

Track gauge (mm) : 500.600, 762 or 900

Traction (KN) : 6.1kN/ 5.74kN

Max.

Traction (KN) : 7.36kN

Speed(km/h) : 10.6km/h/ 7.5km/h

Voltage(V) : 250 Power (KW) : 7.5KW*2

Dimensions Length(mm) : 2700mm/ 2750mm

Width(mm) : 940, 1082 or 1220mm

Height(mm) : 1550

Wheelbase (mm) : 816mm/ 850 mm

Wheel diameter (mm) : Φ650mm/ Φ520 mm

Min Curve radius (m) : 5.7-6 m

Controller : Resistance or IGBT

Braking method : Mechanical or Hydraulic Brake
