Factory Hot Sell Full Color Dip Led Module P16 - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor DIP P16

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

16mm

Screen Dimension:

Customized Size

Certificate:

CE ROHS FCC ISO

Pixel pitch:

PH16

Module size:

256*256mm

Life span:

100000hours

Name:

full color dip led module p16

Other name:

p16 full color led module

Color:

Full-color

LED chip:

Epistar

Warranty:

2 Years

Application:

Square, Adervertising, Bank, Hall, Rent and soon

Packaging & Delivery

Packaging Details:

full color dip led module p16 Packing: Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Factory hot sell full color dip led module p16 Product Description

Specification of full color dip led module p16

No.

specs outdoor full color PH16

1 Pixel structure DIP, 346

2 Pixel pitch 16mm 3 Pixel density 3906dots/Sq.

m.

4 Luminance 6500cd/Sq.

m.

5 Module dimension 256mm(W) * 256mm(H)

6 Module resolution 16 pixel(W) *16pixelmm(H)

7 Module weight 1000g

8 Cabinet dimension 1024* 768mm or other

9 Cabinet area 0.79sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 16m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1400w /Sq.

m.

14 Average power consumption 700w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode static scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
