Nemal5 15 American Female Nema Locking Flanged Outlet Power Receptacle 15a 125v Bl515fo - China

Modle : BL515FO Color ： White Brand name : Bosslyn Certification ： ULE500807 ROHS Grounding : Standard Grounding Housing Material : Nylon Blade Material ： Brass Rated working current ： 15A Rated working voltage ： 125V​​​​​​​ Product features : 1 - America Dupont Nylon construction, resists damage from severe impact, abrasion and chemicals

2 - NEMA Configuration : NEMA L5-15 Power Inlet, 2-Pole, 3-Wire, Grounding

3 - Certified by c( UL)us and UL file number is ULE500807 (Standard: UL 498)

4 - Electric Ratings: 125 Volts, 15 Ampere

5 - Environmental Specifications Flammability: Meets UL94 requirements; V2 rated

6 - Temperature Rating: -40°C to 60°C (-40°F to 140°F) except flat cable:

7 - Temperature Rise: Max.

30ºC (86°F) after 50 cycles of overload at 150% of rated current (DC)

8 - Electrical Specifications Dielectric Voltage: Twice the device rating + 1000V per UL498

9 - Mechanical Specifications Terminal Accommodation: #16 - #8 AWG

10 - Mounting holes interchangeable with competitive units

11 - Back wire terminal clamps for easy, secure wiring

12 - Individual wiring compartments with tapered channel for easy insertion of wires
