Nemal5 15 American Female Nema Locking Flanged Outlet Power Receptacle 15a 125v Bl515fo - China
price: 7.00 Dollar US$
Modle : BL515FO Color : White Brand name : Bosslyn Certification : ULE500807 ROHS Grounding : Standard Grounding Housing Material : Nylon Blade Material : Brass Rated working current : 15A Rated working voltage : 125V Product features : 1 - America Dupont Nylon construction, resists damage from severe impact, abrasion and chemicals
2 - NEMA Configuration : NEMA L5-15 Power Inlet, 2-Pole, 3-Wire, Grounding
3 - Certified by c( UL)us and UL file number is ULE500807 (Standard: UL 498)
4 - Electric Ratings: 125 Volts, 15 Ampere
5 - Environmental Specifications Flammability: Meets UL94 requirements; V2 rated
6 - Temperature Rating: -40°C to 60°C (-40°F to 140°F) except flat cable:
7 - Temperature Rise: Max.
30ºC (86°F) after 50 cycles of overload at 150% of rated current (DC)
8 - Electrical Specifications Dielectric Voltage: Twice the device rating + 1000V per UL498
9 - Mechanical Specifications Terminal Accommodation: #16 - #8 AWG
10 - Mounting holes interchangeable with competitive units
11 - Back wire terminal clamps for easy, secure wiring
12 - Individual wiring compartments with tapered channel for easy insertion of wires
Company Contact:
- Posted By: Guangzhou Bosslyn Electric Co.,Ltd
- Phone: +8618922793822
- Address: 3F Building B No. 17 Hanxi Rd,Hanxi ,Zhongcun Town,Panyu District, GUAGNZHOU , GUANGDONG , China
- Email:
- Website: https://www.bosslyn.com
Published date: July 23, 2019
- Business Description: Guangzhou Bosslyn Electric CO., Ltd started business from 2008 and was founded in 2014 - We are specialized in manufacturing and supplying more than 100 style products, including travel plugs, sockets, global travel plugs, American GFCI Outlet, USB Outlet NEMA Plug connector,Universal Travel Adapter,Travel Plug Adaptor,wall charger,Power plug&Socket,Metal box cover plate and so on, with complete and scientific quality management system.
The products have already passed CE, UL, CCC, VDE, ROHS, BSI, SAA and other product certification, and through the ISO 9001 production management system certification, through the third-party manufacturer of INTERTEK factory inspection certification.
Over the years, we are adhering to the production and management concept of "honesty first, quality first".
