Hccm Impulse Dust Filter - China

HCCM IMPULSE DUST FILTER

Flour Milling Machinery

HCCM

IMPULSE DUST FILTER

•Dusty air passes through cloth sleeves and dust is filtered out by cloth sleeves.

Solenoid valve produces reversed air which blows and cleans the sleeves.

•It is widely used for separating air and dust in normal temperature.

One top section with integrated clean air chamber, rinsing air tank, diaphragm-valves in Alu-housing and rinsing-air jets.

•The sleeve cleaning process is electro-pneumatically controlled at time intervals.

Model Cloth sleeve length (mm) Air volume (m ³/h) Filtrating area (m ²) Discharging power (kw) Weight (kg) Dimension (mm)

HCCM-52 1800-2400 2112-13830 35.2-46.1 1.1+1.1 1505-1584 Φ1580×(3443-4043)

HCCM-78 1800-2400 3090-20730 51.5-69.1 1.1+1.1 2129-2258 Φ1840×(3443-4043)

HCCM-104 1800-2400 4116-27630 68.6-92.1 1.5+1.1 2767-2911 Φ2020×(3443-4043)

HCCM-130 1800-2400 5292-34560 88.2-115.2 1.5+1.1 3304-3469 Φ2350×(3443-4043)
