800l Mash Tun - China
price: check with company for price
800L Mash tun is a vessel used in the mashing process to convert the starches in crushed grains into sugars for fermentation.
TBE mash tuns are insulated to maintain a constant temperature.
The mash tun can be single-function or can also have a false bottom and spigot so that the sparging process can be done in the same vessel.
Steam jacket design will allow The TBE systems are designed to do both decoction mashing and infusion mashing.
The mashing tun/kettle is made out of stainless steel or copper.
Function: Grain mashing
Tank Capacity: 800L (+25% Headspace minimum)
Dimention: Φ1210mmx3100mm
Interior Shell: SUS304 full welded; TH=3mm
Exterior Shell: SUS304 full welded; TH=2mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.4~0.6 μm without dead corner
Insulation: Rock wool; TH=80mm
Heating: No
Steam Jacket: No
Dished top and sloped bottom
Stainless steel top mounted manway
360° coverage CIP spraying ball
4pcs completely SUS304 heavy duty legs with leveling pad
Thermowell for high accuracy temperature sensor
Company Contact:
- Posted By: Shandong Tiantai Beer Equipment Co., Ltd.
- Phone: 531 88161066
- Address: 济南市高新区机场 2668号, 济南 , China
- Email:
Published date: August 14, 2023
- Business Description: Shandong Tiantai Beer Equipment Co., Ltd. is a China based manufacturer and supplier of brewery equipment with more than 20 years experiences.
As an emerging and prospective competitor, we are morn than a supplier to offer the brewery tanks connected by pipings and fittings, but a complete-solution provider to operate the turnkey brewing systems with custom designs for the craft brewers all over the world.
We focus on offering our customers with high quality products and superior services which allow the brewers to minimize the cost but maximize the profits on operating our brewing systems and to produce better beers in wide range of styles.
