Gcan 211 To Can Converter Realize The Mutual Transmission Of Canbus Data - China

Quick Details

Place of Origin: Liaoning, China

Brand Name: GCAN

Model Number: GCAN-211

PC interface: Ethernet interface, RJ45

CANbus interface: Terminal blocks

Ethernet interface: 10 / 100M adaptive

CAN interface: ISO 11898 standard, CAN2.0A/B

CAN baud rate: 5Kbit/s~1Mbit/s

Electrical isolation: 1500V DC-DC

Power supply voltage: 9-30V DC

Power supply curren: 50mA 24V DC Product Feature

■ Power supply: 9~30V(50mA, 24V DC) ■ Working temperature range from -40 to 85 °C ■ CAN-Bus supports CAN2.0A and CAN2.0B frame format, conform to ISO/DIS 11898 standards ■ CAN baud rates range from 5Kbps to 1Mbps ■ CAN-Bus interface with electrical isolation ■ CAN-Bus insulation voltage: DC 1500V ■ Standard Ethernet interface: RJ45 ■ Supports 10 / 100M adaptive ■ The working port, the target IP and the target port can be modified ■ Support agreement: ETHERNET, ARP, IP, ICMP, UDP, DHCP, DNS, TCP ■ Compatible with SOCKET work (TCP Server, TCP Client, UDP) ■ 2.4G WLAN interface, in line with IEEE802.11a / b / g standard ■ AP mode and station mode
