Infrared Methane Ch4 Sensor Sjh Series - China

Introduction

Miniature NDIR CH4 gas sensor adopts advanced non-dispersive technology to detect and monitor CH4 concentration.

It is with a heated infrared source inside a small chamber, in this case, the inside temperature of the gas sensor is much higher than the outside which can avoid condensing events and the high humidity influence .

Besides, the PCB inside the gas sensor is specially treated for corrosion protection.

Features:

1 - NDIR technology, with longlifespan

2 - Diffusion sampling, compact size, easy handling

3 - High precision, low power consumption, less maintenance

4 - Self-compensation of temperature

5 - Great resistance to moisture and other gases interference

6 - Voltage output and RS232 output are optional

7 - Good sensitivity and selectivity to CH4 gas Applications

1 - Mine, metallurgy, liquefied gas station, spray paint, petroleum, fuel gas transport etc.

2 - In gas leakage detecting equipment in family and industry

3 - Gas concentration meter.

4 - Combustible CH4 gas leakage alarm or detection Specifications

Measurement range: 0-5%vol (0-100%LEL), 0-100%vol

Working temp: -40℃~70℃

Storage temp: -40℃~ 85℃

humidity range: 0-95%RH(non condensed)

Dimensions: 20*19mm (except pin)

life: >10years
