10W 1.5KVDC isolated Wide Input Voltage DC/DC Converters

The rated output power of TP08DA converters is 10W, 2: 1 wide input Voltage range, the voltage range

is 18V-36V, with Continuous SC protection, it can be widely used in telecommunications, railway

transportation, automation, instruments and etc.

FEATURES

High efficiency, low Ripple&Noise Wide input Voltage range 2: 1 Continuous SC protection, Auto recovery

Operating temperature: -40℃ to 85℃ Two isolated outputs High reliability(MTTF≥100MHo urs)

Universal standard pinout 1.5KVDC isolation /

SELECTION GUIDE

Part Number

Input Voltage Output

Efficiency(Typ)

%

Maximum capacitive

voltage (VDC) load(uF)

voltage(VDC) Current (A)

Rated Range

TP10DA24D12 24(2: 1) 18-36 ±12 ±0.417 86 470

Company Contact:

• Posted By: TOPPOWER

• Phone: 862062162688-809

• Address: Building No.3 ,Rui Fa Road No.15,, Guangzhou , Guangdong , China

• Email:

• Website: https://en.gztoppower.com

• Business Description: Toppower is a professional manufacturing enterprise of DC DC converters.

  We focus on miniature DC DC converters researches, produces and markets,

  Our products have been used in many fields; such as: Industrial Control

  System, Power system, Apparatus and Instrument, Medical facilities, Rail

  transit system, Telecommunication Equipment, Security and Protection

  Equipment and Military Industrial System etc.

  Toppower owns an outstanding researching team.

  The products are 100% inspected and tested automatically by the advanced testing equipment.

  The unique product design, manufacturing process and equipment make our products with high efficiency and very good reliabilities.

  All DC DC converters are made with high quality spare parts and UL 94V 0 package material from the international prestigious suppliers.

  As well, the products meet ROHS requirement and covers 40+ series with thousands of variants from 1 to 50W for your choice.

  Our team targets to support you with professional products and service.

  We also have stocks for the popular variants so as to meet your emergency needs on time.

  we,TOPPOWER can produce:

  0.1W-400W DC-DC converters,1W-30W AC-DC converters,(SIP/DIP/SMD)

  15W-1200W Enclosed /Open frame/DIN RAIL type AC-DC Switching Power supply,

  TOPPOWER quality : ISO9001: 2015, IATF16949: 2016

  Guangzhou Top Power electronics Technology Co., Ltd
