Usb Electrical Slip Rings 1 20 Circuits Power 2 Signals For Automating Machine - China
price: 150.00 Dollar US$
JARCH USB 2.0 Slip Rings+1~20 circuits Power/ 2 signals for Automating Machine Have a Long life, reliable, anti-interference Power/signal Specifications
Circuits 2~22(see table as above) Current Signal(2A) or 10A
Voltage 600 VDC/VAC Max speed 500RPM Housing Material Aluminium Alloy Torque 0.8N.
m
Working life depends on working speed Contact material Precious Metal: Gold-Gold
Electrical noise <10 milliohms Contact Resistance <100mOhm(AWG16#, 300mm)
Dielectric strength 1000VDC@50Hz Lead Wire UL Teflon®
Insulation resistance 1000MΩ@600VDC Lead Lengths 250mm
Operating Temp.
-40°C to 80°C Protection IP51
Mechanical vibratio MIL-SID-810E Humidity 10% to 90% RH
Materials Lead Free, RoHS compliant CE Certified YES
Company Contact:
- Phone: +8613929708571
- Address: Floor 2, Unit C, Guangfa Industrial Park, Dananhai, Luotian Community, Songgang Street, Baoan Dist., Shenzhen , China
- Email:
Published date: November 29, 2018
- Business Description: JARCH is a professional Slip Ring & Routry Joint manufacturer in Shenzhen, China.
Since we were founded in 1998, we have been committed to innovating, developing and manufacturing high quality slip rings and providing perfect rotation solutions for customers around the world.
