Economical Mini 6 Zones Hot Air Reflow Ovens Soldering Smt Machine - China
price: 4000.00 Dollar US$
Specification: Model JAGUAR M6 Heating System Number of heating zones UP 6/BOTTOM6 Length of heating zones 2500MM Heating mode hot air Cooling Mode Force air Cooling zones Up 1 bottom 1 Conveyor System Max.
Width of PCB 350mm Mesh belt width 400mm Transmission Direction L→R(or R→L) Transmission Net Height 880±20mm Transmission type Mesh and chain Range of rail width 0-300mm Conveyor speed 0-1500mm/min Auto/manual Lubrication standard Upper hood method Manual(option: auto) Fixed rail side Front rail fixed(option: rear rail fixed) Components high Top 30mm and bottom 25mm Control system Power supply 5line 3phase 380V 50/60Hz Total power 24kw Starting power 18kw Normal power consumption 4KW Warming time About 20 mins Temp.
setting range Room temperature-300℃ Temp.
control method PLC & PC Temp.
control precision ±1℃ Temp.
deviation on PCB ±2℃ Data storage Process Data and status storage(80GB) Nozzle plate Aluminum Alloy Plate Abnormal Alarm Abnormal temperature.
(extra-high/extra-low temp.
) Board dropped alarm Tower light: Yellow-warming, Green-normal, Red-abnormal General Dimension(L*W*H) 3600×1100×1490mm Weight 900KG Color Computer gray
Company Contact:
- Phone: 13626197803
- Address: Building B,Fuda Industrial Zone,National Highway 107,Shajing,Shenzhen,PRC, SHENZHEN , guangdong , China
- Email:
- Website: http://www.jaguar-ele.com
Published date: December 22, 2017
- Business Description: Were specialized in SMT field for over 10 years with the good quality and pretty competitive price, and our main products include:
-Reflow oven
-AOI, X-ray, SPI
-Pick and place machine
-Wave soldering machine
-Loader and unloader, conveyor and etc.
