Uhf Hf Lf Rfid Handheld And Barcode Scanner Terminal - China

VCH12B

Performance

Operating System Windows Embedded CE 6.0

CPU Freescale i.

MX233 454MHz

Memory RAM 128MB / ROM(TFLASH) 4G(standard)

Interfaces USB2.0(client)

Aoftware Environment C#.

Net programming using MS Visual Studio 2008, the other language can be customized

Application Software Vulcan testing demo

SDK SDK files will be provided for free

UHF RFID Reader(optional)

RFID Frequency (UHF) 865-868/920-925MHz

Protocol Standard (UHF)EPC, GEN2/ISO18000-6C

Read-Write Range (UHF)1meter reliable reading range(this model doesn't support 3.5meter long range UHF RFID feature)

Barcode scanner(1D or 2D scanner)

Barcode reader 1D barcode (Symbol SE955), scanning types: Types: UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc

'2D imager (Hennywell 5180-HD), scanning types: 1D: all major codes;

2D: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX)'

Wireless Communication(optional)

WLAN wifi IEEE 802.11b/g

WWAN GSM/GPRS Dual band (900MHz/1800MHz) or Qual band (850/900/1800/1900MHz)


WPAN Bluetooth, class 2, transmitting range: 5meters/200meters(optiona l)

GPS Ublox chip and packed by MTK from Taiwan(can't be equipped with wifi or Bluetooth at the same time)

Physical Characteristics

Size 179(L)mm*71(W)mm*29.5(H)m m

Weight 350 g

Battery rechargeable polymer battery (3.7V, 3, 000mAh)

Screen 3.2-inch TFT-LCD touch screen (240*320 QVGA), semi-transparent, anti-compact tempered glass

Expansion Slots SIM/PSAM(optional)

Keyboard Intelligent backlight for dark environment use.

Environmental

Environmental Sealing IP65

Drop test 1.5 meters drop test on six sides

Accessories

Standard: Battery, touch stylus, USB cable, charger, Standard Nokia charging cable, hand strap, TF card 4G.



Optional: Charging cradle/cradle with USB port/cradle with RS232 port

Warranty Term

Offer 12months warranty for all Vulcan devices.

Uhf Hf Lf Rfid Handheld And Barcode Scanner Terminal

Please inquiry for your need now
