Cast Steel Melting Kettles Eb4052 - China

High Strength BS3100 A4 Cast Steel Melting Kettles EB4052

A melting pot is a pot in which metals or other substances can be melted or heated up to very high temperatures.

Melting kettle furnaces are designed for the melting and refining of low melting-point nonferrous metals, such as Lead, Tin, Zinc, Al and other alloys.

Detailed Description:

Material Grade: Alloy Steel, Carbon Steel;

Quality Level: As per National Standard & International Standards.

Production Process: Sand Process

Including machining process, such as drilling and tapping holes.

The Trends for Material Selection: due to obvious advantages in terms of service life, maintenance and cost-efficiency, cast steel has been becoming more significant in the melting pot construction over the last few years against both materials, spheroidal cast-iron and lamellar graphite cast-iron.

In comparison with other materials, cast steel offers excellent repair possibilities as it is well-suited to welding.

Special Features:

1 - We can make big size alloy steel castings with Sodium Silicate Sand Process.

2 - We can supply finished alloy steel castings with heat-treatment and machining process.

3 - We can produce alloy Steel castings as per ASTM A27, GB/T 20878, DIN 17440, DIN 17224, AISI, ASTM, JIS SUH35, NF A35-572/584, BS970, BS1449, ISO 683/13.

4 - The biggest steel castings we can achieve so far is 300 tons per piece.

5 - Material Grade for Melting Kettles

Chemical Composition C (Max.

) Si (Max.

) Mn (Max.

) S (Max.

) P (Max.

)

ZG200-400 0.2 0.5 0.8 0.04 0.04

ZG230-450 0.3 0.5 0.9 0.04 0.04

ZG270-500 0.4 0.5 0.9 0.04 0.04

ZG310-570 0.5 0.6 0.9 0.04 0.04

ZG340-640 0.6 0.6 0.9 0.04 0.04
