Metal Diamond Honing Bar - Taiwan

Brief Introductions: Type: Metal diamond bar

Bond: Metal bond

Application: Carbide, glass and ceramic, cast iron, alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials

Specification: Customized

Brand Mark: Moresuperhard

Trade Terms: FOB

Packages: Hard carton

Delivery Time: 15 workdays by express Introductions of Moresuperhard’s Metal Diamond Honing Bar More Super hard provides super abrasive diamond and CBN honing stone, honing sticks for honing machines of almost all renowned honing brands (Sunnen, Nagel, Gehring, Belden, AccuCut, Engis, and other types of high-production honing equipment ).

Our diamond and CBN honing stones are available for precision bore finishing.

Applications Of Diamond honing stone, CBN honing sticks

Materials of workpiece: carbide, glass and ceramic, cast iron, alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials

Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve, oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.

Applicable honing machine: Sunnen, Nagel, Gehring, Belden, AccuCut, Engis, and other types of high-production honing equipment Model Size Grit

diamond and CBN honing stone

honing stick L (mm) Width (mm) Height (mm) 120#～150#

150#～240#

240#~W40

W40~W20

＜W20 16-35 2, 3, 4, 6 2, 3, 4 40, 50 2, 3, 3.5, 4 1, 1.5, 2, 2.5, 3, 3.5, 4 60, 70 1.5, 2, 3, 3.5, 6, 8 2, 2.5, 3, 3.5, 4, 6.5, 7, 8 80, 90 3, 4, 5, 6, 8, 9, 9.5 3, 4, 5, 6, 7, 8, 10 100, 120 2, 3, 5, 6, 8, 9, 12, 15 3, 4, 5, 6, 7, 8, 10, 12, 15 140, 150 3, 5, 6, 8, 9, 12 4, 5, 6, 7, 8, 10, 12 200 8, 10, 15, 20, 40 8, 10, 15, 20 Other specifications honing stone can be made according to customers’ Detailed Specifications can be customized! Guidance of Moresuperhard’s Metal Diamond Honing Bar: Workpiece material Gray iron

Honing Machine Gehring, Nagel

Grinding Tolerance <= 80μm

Mesh Rough D251-D91 Semi D76~D30 Fine D25~D8

Surface finish Ra 0.2 – 1 μm

Liquid Honing oil

Bore diameter, roundness, surface roughness and waviness meet the requirements
