Kopa Wifi Spotting Scope Tw201 20x 60x 240x Optical Zoom - China

Wireless recieve image and record video on your

iPhone, iPad, Android devices

Hard locking case, soft case and tripod included

Fully-coated optics

Built-in sliding sunshade

Water proof, nitrogen purged and fully fog proof

THE WORLD’S FIRST OF WI-FI SPOTTING SCOPE

KoPa Wi-Fi spotting scopeTW201, a versatile high-performance spotting scope offering a wide range of

terrestrial viewing on your iPhone, iPad, Android Phones, and any electronic devices with WiFi function.

It

is not only revolutionary captured viewing but also allows to record video, then effortlessly share with

surrounding WiFi electronics.

Available with advanced Wi-Fi eyepiece, it offering the bright, clear imagery

of our premium fully-coated optics.

Lightweight and compact design travels anywhere, while the rugged, rubber-armored body, masters even

the harshest environments.

Whether you’re hunting the high country or observing wildlife, a KoPa Wi-Fi

spotting scope will help you to transform your most brilliant views into the most valuable dynamic video

and precious pictures.

Application

Athlete training, wirelessly record athlete’s performance

Take archer training as example, any one of them has a spotting scope on their back while shooting an

arrow, with TW201 , archers and their coach can take pictures & record the performance on mobile device

even PC and make comparisons afterwards, coach will know how to advise archers better skills.

TW201

also definitely available for other athlete training.

Narcotics criminal investigation assistance

It should be easier to obtain criminal evidence if drug trafficking happening at a distance, TW201

assistant Narcotics Criminal investigation to record the trafficking process in case they threw drug into

water when police suddenly rushing out and ready to arrest them.

TW201’s portability and Wi-Fi process

abilities should be very powerful police, militaryassistant without any doubt.

Building and urban monitoring

Mountaineering, camping, hiking

Rugged outdoor activities demand portability and durability, TW201 feature rubber armouring, and

waterproofing are ideal when you’re up against the elements, it Wi-Fi functions will help you to save the

exciting moment and share with your teammates on your mobiles phones.

Bird watching, nature watching

With a wide field of view and 20-60x magnification, TW201 are very suited for general nature and bird

viewing.

For animal lover, TW201 is highly recommended for taking pictures and record young bird’s birth

process on iPhone, iPad, and also Android mobile electronics.

Specification

Model: TW201

sensor type: 5M 1/2.5' CMOS

Max resolution: 2592 x 1944 ( 5.0MP)

Image format and frame rate

YUV output

640x480@30fps, 800x600@20fps, 1280x960@10fps, 1280x720@10fps, 2592x1944@5fps

MJPG output

640x480@40fps, 800x600@40fps, 1280x960@40fps, 1280x720@40fps, 2592x1944@15fps

WiFi output

640x480@40fps, 800x600@40fps, 1280x960@20fps, 1280x720@20fps, 1920x1080@10fps

expose mode: wide range auto/manual expose

white balance: auto white balance/auto gain

Focus mode: real-time auto focus/ single auto focus/ manual auto focus

record mode: still picture , real-time video

optical spectrum range: 380-650nm (with IR light filter)

lens diameter: 60mm

magnify times: 20X-60X-240X

Field of view(20x): 2.2°

Field of view(60x): 1.0°

Minimum focus range: 6 m

Optical filming: Filming for all surface

wireless parameter

wireless protocol: IEEE 802.11b/g/n

Frequency range: 2.4000-2.4835GHz

broadband transmission: 150Mbps

interface type

signal interface: Mini USB interface

operate system requirement

operating temperature(Centigrade): - 10~50

saving temperature: -20~60

operating humidity: 30~80%HR

saving humidity: 10~60%HR

power supply

built-in rechargeable lithium battery

DC 5V USB power supply by PC

DC 5V 1.5 A adapter

software environment

operating system: Microsoft® Windows® XP / Vista / 7 / 8(32 & 64 bit) （USB working and Wifi working

mode)

MAC OS X （WiFi working mode）

IOS5/IOS6（WiFi working mode

hardware requirement

CPU: equal to Intel Core2 1.6GHz or higher

memory: 2GB or higher

USB interface: USB2.0 High-speed port

DVD-ROM（will require when install software）

structure parameter

product size: φ55x549

gross weight: 2.87KG(include tripod）
