Top Mounted Eccentric Semi Ball Valve - China

On the base of eccentric semi- ball valve, Top entry entry eccentric semi-

ball valve was developed .

They are widely used in the water system

which including tiny solid particle medium, such as the South- North

Water Diversion Project .

Benefits

1 Full bore design , small pressure loss ;

2 - Lower opening torque , which is less than half of the same size ball valve ;

3 - Easy to maintain: It is not required removing from the pipe when valve repair, as long as you open the valve cover .

4 - Large size can be designed , max up to DN2000.

5 - With anti- scaling function

Technical specifications

Size : DN100~DN1400

Pressure ：PN1.0~PN1.6MPa

Body material：WCB

Sealing material: Hard alloy or special treatment by spraying .

Connect method : Flange, weld

Driving method: worm gear , pneumatic , electric etc

Application

Water industry

Municipal Engineering
