High Power Electrode - China

Artifical graphite electrodes is made of high-quality low ash materials, like the petroleum coke, needle coke and coal pitch.

After experiencing calcinations, burdening, kneading, forming, baking and pressure impregnation, it is graphitized in a hign temperature of over 3000℃, And then treated with machining.

this kind of product is widely used for electric arc steel-making, yellow phosphorus, indusreial silicon, other alloys and non-metallic materials of electric atc furnace.

this product is characterized by low resistivity, good electrical conductivity, low ash, even and compact structure, good antioxidation and high mechanical strength

High power

Project Nominal diameter /mm 200-400 450-500 550-700

Resistivity / μΩ•m ≦ Electrode 7 7.5 7.5 Joint 6.3 6.3 6.3

Flexural strength / Mpa ≧ Electrode 10.5 10 8.5 Joint 17 17 17

Elastic modulus / Gpa ≦ Electrode 14 14 14 Joint 16 16 16

Bulk density / g/cm3 ≧ Electrode 1.6 1.6 1.6 Joint 1.72 1.72 1.72

Thermal expansion coeffi 10-6/℃ ≦ Electrode 2.4 2.4 2.4

cient / Joint 2.2 2.2 2.2

Ash / % 　 ≦ 　 0.5 0.5 0.5 Size and permissble variation of Graphite Electrode

Nominal Actual diameter Nominal length Actual 　

diameter length 　 Maxmum Minmal Black part is the Allow Short feet

　 smallest deviation Inches mm

10 250 256 251 248 1600/1800/2000 ±100 -275

12 300 307 302 299 14 350 357 352 349 16 400 409 403 400 1600/1800/2000/2200 18 450 460 454 451 20 500 511 505 502 1800/2000/2200/2400 22 550 562 556 553 24 600 613 607 604 2000/2200/2400/2700 Graphite Electrode, Carbon Graphite Electrode, UHP Electrode, HP Electrode Wholesaler

Find here details of ShouShan selling high power graphite electrode and high strength graphite electrode.

All the low ash graphite electrodes with super quality and competitive price.

Our company is a leader in the industry and we will not disappoint you.

Company Contact:

• Posted By: Liaoyang Shoushan Carbon Factory

• Phone: 13555874341

• Address: NO.85 North of Liaoan Road, Liaoyang , LIAONING , China

• Email:

• Website: http://www.lstcarbon.com/

• Business Description: LiaoYang ShouShan carbon factory was established in 1994, which located at the foot of the ShouShan Mountain with the superior geographical position location and convenient transportation.

  the factory covers the area of 58000square meters and holds the fixed assets 50 million RMB.

  LiaoYang ShouShan carbon factory is the specialized enterprise and the business includes : production , operation , scientific research and domestic and foreign trade , with the advanced management concept and the extensive market prospect.

  in addition , the factory concept is “build the unique brand and create the top raking-Graphite Electrode manufacturing base in China” on the other hand , Shoushan carbon factory have the ultra-high power, high power and the regular graphite electrode production line with ISO9001 international quality system authentication, and especially focus on the Ф200-Ф600 specification ultra-high power.

  Our main products are: graphite electrode, graphite block, carbon block, graphite crushing and silicon carbide, the annual comprehensive production capacity can achieve 15000 tons.

  ShouShan carbon factory is expanding 50000 tons Ф500-Ф700 ultra-high power graphite electrode production line, and plans to gradually put into operation in 2018

  Moreover, Shoushan carbon factory have the manages product adhere to the “quality first with credit management for this service for sincere “concept.

  Finally , we seek common business opportunities and common development to the cooperative partners in domestic and overseas.
