Signal Pneumatic Electric Slip Ring For Rotating Equipment - China

Transmission of 4 Passage gas 18 circuits signal Pneumatic Electric Slip Ring for rotating equipment Feature: 4 passages pneumatic

6-24 electrical circuits signal available

Max speed: 500rpm Housing material: Aluminium Alloy Contact material: Gold to Gold Quick Details: Model Number: JSR-MRQ04-05-18E Passage Size(mm): 3mm

Passage Media: compress air Electrical Circuits: 6 - 24 Volt AC/DC(V): mV~240Vac/Vdc Current(A): 2A

Speed(rpm): 500RPM Tube Size 4mm, 6mm Description: Slip rings can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure.

JSR-MQR Series Pneumatic Electrical Rotary Union Support 2-24 passage way Pneumatic/Hydraulic, it can combine with power, signal, Ethernet, USB, Devicenet, Control Net, Canbus on request.

It also could be mounted by shaft or optional flange mounting.

Passage media types can use Air/Gas, Chemical, DI / Tap Water, Oil, Water/Glycol.

The JSR-MQR4H-xE provide 4 passage 3mm compressed air, combine 6~ 24 circiuts Power and singnal or Ethernet electrical slip ring.

The slip ring provide a rotary flange can be install on a rotary table.

Benefits: · Unique signal handling performance with minimal electrical circuit noise

· Tight packaging to fit in the most demanding space constraints

· Fully compatible with both analog and TTL control level signals

· Precision ball bearings for long life

· Sealed units available, IP67 optional

· Rugged anodized aluminum construction

· Low Cost, Preferential prices · Small size

· Rapid delivery
