Wholesale Cheap Promotional P10 Smd Led Wall Module - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P10

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

Video

Pixels:

10mm

Screen Dimension:

Customized

Name:

p10 smd led wall module

Other name:

Wholesale Cheap p10 smd led wall module

Certificate:

CE ROHS FCC

Brightness:

>7000cd/sqm

Color:

Full-color

Application:

Live Events Led Display

Warranty:

2years

Module size:

320*160 mm

Life span:

100000hours

Pixel pitch:

10 mm

Packaging & Delivery

Packaging Details:

p10 smd led wall module Packing: pearl wool + carton + wooden case or flight case

Delivery Detail:

Shipped in 15 days after payment

Wholesale Cheap promotional p10 smd led wall module Product Description

Specification of p10 smd led wall module

No.

specs outdoor full color PH10

1 Pixel structure SMD, 3535

2 Pixel pitch 10mm 3 Pixel density 10000dots/Sq.

m.

4 Luminance 7000cd/Sq.

m.

5 Module dimension 320mm(W) * 160mm(H)

6 Module resolution 32 pixel(W) *16pixelmm(H)

7 Module weight 400g

8 Cabinet dimension 960 * 960mm or other

9 Cabinet area 0.92 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 10m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1650w /Sq.

m.

14 Average power consumption 825w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/2 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available

Company Contact:

• Posted By: Shanghai Ledlord Optoelectronice Co., Ltd.

• Phone: +86 021 60709506-820

• Address: No.5239 Beisong Rd, Songjiang district., Shanghai , Shanghai , China

• Email:

• Website: http://www.ledlord.cn

• Business Description: Shanghai Ledlord Optoelectronic Co., Ltd. is a high-tech enterprise, committed to LED display R&D, manufacturing, sales, installation, debugging, service and providing customers with a complete set of solutions and OEM services.

  With years of experience, Ledlord has been one of the most trusted led manufacturers in East China.

  In the future, Ledlord will face the global market, which has been exported to South Korea, India, Spain, Russia, Guatemala, Singapore, Turkey, the United States, etc.

  The products include advertising, bank, real-estate, stadium, exhibition hall, curtain wall, leasing and so on.

  Ledlord has professional engineering and technical R & D group, who continuously carries on product development and production process improvement, providing customers with the most competitive product.

  With the guide of business philosophy "criterion, innovation

  concentration" , Ledlord has got more than tenpatents technologies.

  Ledlord comprehensively enforces international management.

  All products have been through the high and low temperature, dust proof, waterproof and vibration test.

  Outdoor products have been reached IP66 or above standards.

  Ledlord Electronics LED display is the guarantee of industry quality and confidence, who strictly improves the Quality Management System on the basis of the quality system ISO: 9001: 2008 - Ledlord products have passed CCC, CE, FCC and RoHS certifications, which highly ensure the LED products reliable performance and customers high quality requirements.
