Ckfl Sf6 Gas Insulated Switchgear - China

1 - Description

CKFL SF6 gas- insulated switchgear is a completely sealed &

insulated medium voltage ring main unit working in a voltage

range maximum up to 24kV.

2 - Working Condition

2.1 Altitude: ≤ 1500m

2.2 Ambient air temperature: - 35℃ ～ +40℃

2.3 Max.

average daily temperature: +40℃ Max.

annual

average temperature: +35℃

2.4 Wind speed: ≤ 34m/ s

2.5 Relative air humidity: ≤ 90% ( +25℃ )

2.6 Ground gradient: ≤ 5°

2.7 Earthquake intensity: ≤ magnitude 8

2.8 Applicable in the places without fire, without explosion

risk, without chemical corrosive and without violent

vibration

( Exceeding above working condition is available as

customized product)

3 - Available modules options

● CKFL- □ / C- - - - - Load switch module

● CKFL- □ / F- - - - - Switch- fuse combination module

● CKFL- □ / V- - - - - Vacuum- circuit breaker module

● CKFL- □ / D- - - - - Direct incoming/ outgoing cable module

● CKFL- □ / CL- - - - - Busbar sectionalizer module( load switch)

● CKFL- □ / CvKr- - - - - Busbar sectionalizer module( vacuum

switch)

● CKFL- □ / PT- - - - - Potential transformer module

● CKFL- □ / M- - - - - Metering module

4 - Standard

- - - - IEC62271- 1

- - - - IEC62271- 100

- - - - IEC62271- 200

- - - - IEC60265- 1

- - - - IEC62271- 102

- - - - GB/ T11022

- - - - GB/ T3804

- - - - GB/ T1984, GB1985
