Wanlida Dynamic Reactive Power Compensator - China

Application industrial fields

Rolling Mill

The big reactive impulsion caused by rolling mills and other

industrial symmetric loads may lead to the following

problems to the power grid:

The voltage drop and fluctuation, which may result in

malfunction of electric equipment and reduce the productive

efficiency.

Low power factor

The harmful high-order harmonic waves in the driving

devices, typically 5th, 7th, 11th, 13th and side-

frequencies, which will cause serious voltage distortion.

Electric Arc Furnace (EAF) and Ladle Furnace

The electric arc furnace and ladle furnace are typical non-

linear and erratic loads in the power grid, causing a series

of adverse effects to the power grid:

Result in serious three-phase unbalance of the power grid,

and cause negative-sequence currents.

Produce high order harmonics, such as coexist of 2nd, 4th

even harmonics and 3rd, 5th, 7th odd harmonic, which make

severe voltage distortion become more complicated.

Serious voltage flickers

Electric Railway Traction Substation

While protecting the environment, the electric locomotive

also causes serious pollution to the power grid.

As the

electric locomotive is powered by single phase power system,

which not only causes serious three-phase unbalance and low

power factor but also generates negative-sequence currents.

Currently, the only way to solve the problem is to install

SVC system at appropriate locations along the railway.

The

SVC is able to balance the three-phase by means of single-

phase compensating and to increase the power factor through

filter capacitor.

Wanlida’s SVC is capable of solving this

problem perfectly at minimum cost.

Hoists and Other Heavy Industrial Loads

The hoists and other heavy industrial loads may cause the

following effects to the power grid when they are at working

state:

Cause the voltage drop and voltage fluctuation in the power

grid.

The harmful high-order harmonic currents

Wanlida’s SVC can solve above problems perfectly and help

customers obtain the following benefits:

Increase the power factor by dynamic reactive power

compensation

Eliminate the voltage distortion caused by harmonic

Stabilize the voltage and reduce the voltage fluctuation and

flicker

Balance the three-phase load current and eliminate the

negative sequence current

Increase the operation safety of impact loading equipment

and its adjacent electrical equipment

Long Distance Power Transmission

The power grid tends to have larger capacity and longer

distance, in the case of long-distance AC transmission, due

to the influence of Ferranti Effect, the voltage in the

middle of transmission lines will rise which will limit the

transferred power.

The capacitive power along the long

distance power transmission lines is in proportion to the

cable length and the square of voltage, so it will be

terribly surprising for capacitive current power to ground,

which results in the voltage rising of 1.5 to 2 times of

rated voltage at the end of transmission line and then

causes badly result.

The power utility usually install shunt

reactor to compensate capacitive current to ground to solve

voltage rising at the end of transmission lines, but if the

shunt reactor is of fixed capacity, it will be removed from

compensation system once inductive current is over desired

capacitive current to ground.

As usual, the operation of

shunt reactor connected in parallel to transmission line

wants a very high demand for switch, but until now, it is

still very difficulty to solve the over-voltage surge caused

by reclosing of switch, as a result, it results in bad over-

voltage accidents.

However, the SVC of MCR type of Wanlida

can solve those problems; it can regulate reactive power of

transmission line dynamically and fast.

The SVC of TCR can

not be directly installed in transmission lines with over

35KV, but the SVC of MCR can be installed in extra-high

voltage and ultra-high voltage transmission lines directly,

and it has no need of action of switching.

So the SVC of MCR

type is able to improve transmission and distribution

performance of the power system remarkably.

It should be

installed at one or several proper points in the power grid

in order to maintain a balanced voltage under different

conditions and achieve the following purposes:

Stabilize voltage of a weak system

Reduce the transmission losses

Enhance transmission capability and make existing power grid

more efficient

Improve transient stability

Increase the resistance in the small interference

Improve system damping

Enhance the voltage control and stability

Restrain the power oscillation and the sub-synchronous

resonance

Wind Power Plant

The output power of generator is always fluctuated

frequently because of variable wind power.

At present, the

popular asynchronous wind generator (including Doubly-Fed

Type) needs to absorb parts of inductive reactive power to

build magnetic fields, the paralleled capacitor banks can

realize compensation, but the stepped switching capacitor

banks can not meet fast and dynamic reactive power

compensation demand caused by variable wind power,

sometimes, if the capacitor banks can not meet reactive

power compensation in time, the wind generator will absorb

reactive power from the upper power grid, which will result

in low power factor of upper power grid and then cause

voltage fluctuation, so the state grid put forward the <

Regulations on State Grid Corporation Wind Farm Grid Access

Technology (Amendment)> based on voltage fluctuation,

flicker, frequency deviation, harmonics and lacking reactive

power.

The SVC of MCR can solve the above problems to meet the

demand of utility.

Secondary Substation (66KV to 110 kV)

In the regional power grid, the stepped switching capacitor

banks are used to compensate the system reactive power and

increase the power factor.

But they are only able to provide

the capacitive reactive power, and unable to realize rapid

and accurate adjustment according to the load variation, so

sometimes they provide much more reactive power than the

actual desired reactive power, which will result in over

voltage of the bus bar and damage the electric equipment and

destroy system stability.

Because the SVC of TCR can not be directly installed in

subtransmission lines with over 35KV, Wanlida’s SVC of MCR

will be most suitable for subtransmission, Wanlida’s SVC

system is able to compensate with capacitive and inductive

reactive power rapidly and accurately.

It solves the

problems of reactive feedback effectively.

In addition, when

a new SVC system is installed, the existing fixed capacitor

banks can be utilized by adding a MCR, which requires the

minimum investment.

It is the most effective way to improve

the power quality of the local power grid, the detail

benefits is as below:

Reduce the reactive power exchange with system and improve

system stability

Rapidly and continuously compensate the reactive power,

increase the power factor and improve the power quality.

Reduce the power losses of distribution system

Used in combination of stepped switching capacitor banks to

reduce the damage caused by frequent switching of capacitor

bank.
