Sun Gold Power 600w 24v Wind Solar Hybrid Charge Controller Lcd Display - China

TECHNICAL PARAMETERS:

Model: SG-WCL60024

Rated Battery Voltage: 24V

Rated Wind Turbine Power: 600W

Wind Turbine Maximum Input Power: 1000W

Rated Solar Power: 300W

Wind Turbine Maximum Input Current: 40A

Unload Voltage（factory default）: 28V

Unload Current（factory default）: 25A

Dumpload Start Voltage（factory default）: 27V

Charge Shutoff Voltage（factory default）: 29V

Wind Turbine Brake Current: 25A

Battery Over Discharge Protection Voltage: 21.6V

Battery Over Discharge Recovery Voltage: 24V

Output Over Voltage Protection: 32V

Light Control On Voltage (Factory Default): Adjustable（2Vʌ 89;

Light Control Off Voltage (Factory Default): Adjustable（3Vʌ 89;

Load 1 Rated Output Current: 10A

Load 2 Rated Output Current: 10A

Load 1 Output Mode(Factory Default):

3 Modes Selection（Light-Co ntrol On and Light-Control Off）

Load 2 Output Mode(Factory Default)

3 Modes Selection（Light-Co ntrol On and Time-Control 5 hours Off）

Control Mode: PWM

Display Mode: LCD

Display Parameters:

Wind Turbine Power, Wind Turbine Voltage, Wind Turbine Current, PV Voltage, PV Charge Current, PV Power, Battery Voltage,

Over Voltage, Under Voltage, Over Load, Short Circuit, Night.

Etc

Working Temperature & Humidity: -20~+55℃/35~85%RH&# 65288;Without Condensation）

Temperature Compensation（optio nal）: -4mV/℃/ 2V , –35℃-+80℃, Precision ±1℃

Communication Mode（optionalʌ 89;: RS232, RS485, RJ45, GPRS.

Etc

Quiescent Current: ≤20mA

Weight and Size: 142×150×82mm, 1.9kg

PERFORMANCE FEATURES:

- Superior military-grade components to ensure the product stability.

- Perfect protection function, thus the system has higher reliability.

- Check and set all operation parameters as requirement from LCD display.

- Voltage limiting and current-limiting charge mode, ensures battery in the best charging status.

- Two DC Load output, light-control, time-control, constant output, and multiple output control mode selection.

- PWM stepless unload mode, which burn the excess power into dump load, making the battery charging in best status.

- Design of high quality aluminum alloy appearance, with small size and good cooling effect.

- European CE certification.
