UHD LED Display

1.1

UHD-P1.583 LED Display Screen

Summary

UHD-P1.583 LED Display Screen:

* High-brightness, high-resolution indoor LED display

* Perfectly aligned images

* Front access

Specifications

ITEM P1.583

Pixel Pitch(mm) 1.583

Pixel Density(pixel/m2) 400000

Pixel Component 1R1G1B

LED Configuration SMD1010

Panel Dimension(W×H)mm 304*171

Scan Mode 1/32

Cabinet Dimension(W×H)mm 608*342

Cabinet Material Die-casting Aluminum

Cabinet Weight(㎏) 8

Brightness(cd/m2) ≥800( Color Temperature6500K)

Color Temperature 3200K-9500K

Viewing Angle(V) 160°

Viewing Angle(H) 160°

Contrast Ratio 3000: 1

Max Power Consumption(w/m2) 1000

Ave Power Consumption(w/m2) 350

Operating Power Source AC85~264V(47-63Hz)

Frame Frequency(Frame/S) 60

Refresh Rate(Hz) ≥2880

Gray Level RGB65536Grade

Brightness Adjustment Level 256Grade

Brightness Adjustment Mode Manual/Automatic/Programm able

Control Distance UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km

Operating Temp ﹣20℃－﹢50℃

Operating Humidity 10%－90%RH

Protecting Rating IP31

MTBF ＞10000h

LEDLife Span ＞100000h

LEDBest View distance 5m-150m
