Microwave Sensor 60w Solar Parking Lot Lighting - China

Microwave sensor 60w solar parking lot lighting series pv2 all in one solar parking lot light

model

zgsm-pv706027

application

street | road | highway | parking lot | path | microwave sensor solar led light

key features

1 - wide power range: 10w~60w.

2 - special circuit design, single leds damage won't affect others' normal work.

3 - high lumen output up to 145lm/ w with high quality led chips.

4 - lithium batteryimproves the reliability of the luminaire.

5 - monocrystalline silicon solar panels, greatly improving solar energy conversion efficiency.

6 - smart mppt controller realizes intelligent control of lamps.

7 - multiple lighting control options are available, e.g. motion sensor, pir sensor.

specifications

model zgsm-pv706027

led number 90units

nominal power 60w

battery spec.

27ah /11.1v

solar panel spec.

monocrystal 70w /18v

led brand philips lumileds 3030 2d

luminous flux 7800lm

light type 1s

cct 3000k.

4000k.

5000k.

5700k

charge time <4.5 hours (low battery voltage)

worktime at energy

-saving model(30%) more than 13 hours

discharge temperature -20℃~+60℃

charge temperature <60℃

light control voltage 5-11v

mounting height 6-8m

space between light 18~35m

pole diamerter fixture round pole: Φ60~85mm; square pole : 60 x60 ~77 x77mm

rating ip65 ik10

induction type human infrared induction or microwave induction function

certification ce, rohs, lm80

warranty period 3 years packing details

fixture dimension 1120x426x229mm

fixture weight 17.8kg

packing dimension 1175x485x140mm

packing weight 19.4kg
