Led Message Sign - China

LED Message Sign

Programmable Led Sign

Wifi Programmable Led Message Board

Specifications

1 - High brightness 12000nits

2 - Outdoor waterproof IP68

3 - CE ROHS ETL SGS SAA Fcc UL

4 - Low power consumption

5 - AC110-240V

Technical parameter

Unit board Pixel pitch 10mm Module size 160mm*160mm ( 320mm*160mm, 320mm*320mm) Resolution of module 16*16dots Density of pixel 10000dots/m2 Pixel configuration LED346 1R1G1B

Main Technical parameter Red wavelength 620-630nm; 750-900mcd Green wavelength 525-530nm;1900-2100mcd Blue wavelength 465-470nm;350-450mcd Colors 16777216 Best viewing distance 8-160m Horizontal/Vertical Viewing angle 120 degree/60 degree Gray scale 16bits per color Color temperature 6500k Brightness More than 6500cd/sqm IP grade Front : IP67 back: IP65 Frame frequency 60HZ Refresh frequency ≥2000HZ Control method Synchronization/Asynchron ization Drive method 1/4 Scan Temperature Storage: -30°C-+85°C Working: -20°C-+65°C Operating ambient humidity 10%—95%RH Earth leakage current < 2mA Defects rate.

≤0.00001(Led display line standard<0.0001) Flatness Tolerance of interpixel ≤0.3mm Tolerance of modules clearance ≤0.6mm MTBF More than 10, 000 hours Life span More than 100, 000hours

Power Operating voltage AC110V/220V±10% Maximum/Average power consumption 800/350w/m2 Current ≤20mA(single LED) Power switch Automatic switch

Control system CPU Pentium4 or above Signal Input Composite, S-video, Component, VGA, DVI, HDMI, SDI, HD_SDI, etc Controlling system main controller card+optical fiber transmission Control method Asynchronization Systems operating platforms WinXP, Win2000, Vista, Win7, Win8 etc.

Softer ware LED media player
